The use of premium quality components, extensive shielding and low noise linear on board power supply regulation has resulted in systems with extremely low crosstalk and noise levels. Matrix switch corporation analog video routers can be used standalone or combined with additional analog video routers to produce a 2 channel YV router or 3 channel YUV or RGB router. When used in conjunction with the LCD remote control panel, multiple analog video routers can be combined to expand the available input or output channels, using cascaded systems or input replication respectively. These video routers can be combined with Matrix switch corporation Analog Audio or AES Digital Audio routers, by connecting them with a D25 straight male to male through cable. The choice of a button control panel or status only panel provides an additional savings opportunity for applications that utilize a remote control panel or are only controlled via the webpage interface, telnet or RS-232 serial. FeaturesStatus only front panel no button control for lower purchase priceInteractive web page interfaceVertical interval switchingStore and recall up to 10 presets complete or partial state recallSoftware updates via ethernet portFlexible control via a text based protocol over TCP/IP port, rs-232 serial or web page interfaceCompatible with TCP/IP remote panelsOptional 75 ohm aes digital audio separate unit connected via d25 afv connectorOptional balanced analog stereo audio separate unit connected via d25 afv connectorSupports audio break away when connected to an audio routerSpecificationsPower: 115 VAC 60HzStorage Temp: -10 Through +50 Deg COperating Temp: 0 Through +40 Deg CConnector type: BNCInput impedance: 75 OhmsNominal input level: 1V P-PMaximum input level: +/-2V P-POutput impedance: 75 OhmsNominal Output Level: 1V P-PMaximum output levelOverall gain Unity: +/-1% into a 75 ohm terminationDimension: 3.5'' H x 19'' W x 14'' D
