John Deere Z530M 54-in 24-HP Zero-Turn Mower Bagging Collection; Includes Zero-Turn Mower; Power Flow™ Blower, Chute, Bagger, & Attachment Bar
Collection Items
SUCCESSWhen should I expect to get my items?
See availability by item




Items Included in this Collection





Item #2593133 |
Model #BG21196
Built in Greeneville, TN, USA using domestic and imported materials
The 24 HP John Deere Branded Kawasaki V-Twin engine has plenty of power and torque for the Z530M to handle tough mulching, mowing, and bagging conditions – most suitable for a flat with obstacles terrain, two plus acres
Mow well fast with the 54-in triple blade Accel Deep™ Mower Deck engineered to process tall grass at faster speeds
Dual Hydrostatic Tuff Torq® transmission with 1-in axles for power and durability, maximum speed 8-mph - steer using motion control levers, effective over long, level tracks of land or around trees, shrubs and flower beds
Comfortable 20-in cut and sewn seat with armrests and ComfortGlide™ suspension, cup holder, side and under seat storage compartments, foot lift, color coded controls for easy identification and low-fuel warning light visible in daylight
The Z530M is equipped with a foldable Roll-Gard rollover protective structure (ROPS) and retractable seat belt - rubber floor mats, foot lift and premium handlebars come standard on the Z530M
Parts/attachments: 54-in mulch kit (2636757), 54-in material collection system (2636755, 777832, 651439, 2636764), LED light kit (2636766), foot pegs (2636767)
Trash receptacle (2636759), attachment bar (2636764), hitch kit (2636765), oil (48763), oil filter (228877), air filter (2758977), 54-in blades (698348), 54-in belt (712122)
Hassle-Free Ownership: John Deere 4-year/300-hour bumper to bumper warranty, local John Deere dealer support and a 10-Point Pre-Delivery Inspection prior to sale
General | |||
|---|---|---|---|
Deck Engagement Type | Electric | Start Type | Turn key start |
Deck Type | Stamped | Transmission Type | Dual hydrostatic |
Type | Zero-turn riding lawn mower | Blade Speed (RPM) | 0 |
Battery Type | Lead acid | Power Source | Gas |
Blade Engagement Type (PTO) | Electric | Series Name | Z530M |
Deck Material | Steel | Color/Finish Family | Green |
Drive Type | Rear wheel drive | Oil Filter Type | Standard |
Engine Type | V-twin | Number of Deck/Anti-Scalp Wheels | 4 |
Seat Type | High-back with lumbar support and arm rests | ||
Dimensions | |||
|---|---|---|---|
Cut Height Adjustment | 12-position | Rear Wheel Size | 22-in |
Mower Deck Width (Inches) | 54 | Size of Deck Wheels | 5-in |
Weight (lbs.) | 780 | Minimum Cutting Height (Inches) | 1 |
Cut Width (Inches) | 54 | Maximum Cutting Height (Inches) | 4 |
Front Wheel Size | 13-in | Overall Width with Deck (Inches) | 68.6 |
Fuel Capacity (Gallons) | 4.5 | Engine Oil Capacity (oz.) | 70.4 |
Overall Length (Inches) | 76.9 | ||
Features | |||
|---|---|---|---|
Deck Lift System | Manual | Grease Fittings | Yes |
Grass Deflector | Yes | Maximum Forward Speed (MPH) | 8 |
Headlight(s) | No | Maximum Reverse Speed (MPH) | 4 |
Model Description | Z530M ZTR 54-In 24 HP Kawasaki V-Twin | Turning Radius (Inches) | 0 |
Number of Blades | 3 | Commercial/Residential | Residential |
Ammeter | Yes | Charger Included | No |
Bagger Included | No | Lowe's Exclusive | Yes |
Cruise Control | No | Mulching Capable | Yes (kit sold separately) |
Cup Holder | Yes | Engine Oil Included | Yes |
Deck Gauge | 10 | Engine Horsepower | 24 |
Discharge Location | Side | Bagger Capable | Yes |
Engine Brand | Kawasaki | Operator-Controlled Mow-in-Reverse | Yes |
Engine Displacement (Cu. Centimeters) | 726 | Trailer Hitch Included | No |
Engine Series | John Deere Branded Kawasaki | Removable Battery | Yes |
Front Axle | Cast iron | ||
Compatibility | |||
|---|---|---|---|
Matching Mulch Kit (Item #) | 2636757 | Recommended Yard Size | 3 to 5 acres |
Replacement Blade OEM Part Number | 2916862 | Recommended Terrain Type | Flat with obstacles |
Replacement Belt OEM Part Number | GX25998 | Attachment Compatible | Rear |
Warranty | |||
|---|---|---|---|
Warranty | 4-year limited or 300 hours | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 21101700 | ||
Ratings may include incentivized customer reviews.
What Customers Are Saying
Customers overwhelmingly praise this mower for exceptional cutting performance, comfort, and durability. Most highlight the clean, uniform cut even in wet or tall grass, with a powerful 24 HP engine handling heavy use effortlessly. The comfortable seat, smooth ride, and responsive steering earn consistent acclaim, while solid construction and user-friendly features like intuitive deck height adjustment and larger fuel cap impress reviewers. A few report isolated issues like rough cranking sounds or minor paint concerns, but these are uncommon. Overall, most customers consider this a significant upgrade and highly recommend it.
Customer review summary generated by AI, including incentivized reviews.Fast and Fun
I've only had this for about two months, but I'm very happy with it so far. I was previously using a very old, very reliable lawn tractor, but it was taking forever to mow about 2 acres full of obstacles. My neck and shoulders ached from the constant cranking on the steering wheel. Although the old rider had a "cruise" setting, I couldn't use it enough to relieve the pressure on my lower back from pushing the forward and reverse pedal for a few hours every week. The PROS: The Z mower is way mo...
From JohnDeere
Hassle free purchase!
The sales representative Frida was very helpful in helping me with my iPhone as I had to set up my multiple identification. This was a promotion purchase and I needed my credit limit increased which she did for me without a hitch. I was in and out with my new Lawn mower in less than an hour. Got it home I made two passes and realized I need to make a slight leveling adjustment which I did with ease. Lawn looks great! with no problems. I look forward to more promo opportunities in the future. Mu...
Verified Purchaser
Thanks for your review. We appreciate your comments!
Handles great and cuts great,, plus other great fe
The mower is slow to start from a cold start I’m not very impressed with that,, other than myself having trouble getting used to operating it ( cutting a straight line) is a hoot to watch, my wife took to it though like a duck to water,,, awesome machine, I strongly recommend it.
Verified Purchaser
Thanks for bringing this to our attention. We appreciate the feedback.
What an awesomely built mower
I've used it once (so far) on our newly acquired 2.1 acre sloping property and it handled everything I threw at it, from tall (2feet) to short (5 inches) of natural growth. It was my first experience with a Zero Turn mower but it was an easy and intuitive operation. I'm king of my neighborhood now. Since my purchase and first mow using the Z530M, I've purchased the rear-bumper, the rear hitch, the foot-pegs, the mulching package and blades, and the string-trimmer rack. I'm good to go and can...
The lawn mower is great! But the experience buying the mower was phenomenal! Tanisha and Gabe were amazing! Tanisha was on the floor helping people and came up to me to help and I had no idea she was the store manager! She was helping people like she was a regular associate! Leading by example for sure! The teamwork that these two associates showed was top-tier! I was just looking at lawn mowers that day! When I left I had a credit card (0% interest can’t go wrong there) and a brand new lawn mow...
Verified Purchaser
Great upgrade from a Z315E
After moving and having to mow 2 acres I was thinking the Z315E I had was a little less machine than I needed for the additional yard (previously was mowing 2/3 acre). The Z530M takes about 30 minutes off the mowing time with the Z315E and is a much more comfortable and stable feeling ride. I really like the Comfort Glide suspension and seat. The 54" cutting deck is a great size for cutting for grass per swipe and still being able to trim around gardens and other lawn features. I also like t...
From JohnDeere
Thanks for taking the time to share your experience. Your feedback is valuable to us.
Not bad, but a few things to fix
Good and reliable mower. I'd give it 3.5 stars overall. Great handling, easy to work, and cuts my mowing time in half from standard mowers. The 2 things that bring it down are the amount of dust and clippings that come out from under the front of the mowing deck and blow right in your face as you are mowing. There needs to be a flap or brush piece in the front to prevent this from happening. The second is that you feel every bump on the ground as you mow. It has a drink holder, but if I carried ...
From JohnDeere
Thanks for taking the time to share your experience. Your feedback is important to us.
Great mower for lawns and small fields
I purchased my Z530M zero-turn mower just over a month ago and have been extremely impressed with its performance. I maintain nearly 2 acres of property. Because we’ve had over 10 inches of rain in the past month, I’ve had to mow every single week without fail. Even when the grass has been exceptionally tall—including field grass up to 18 inches high—the mower has powered through without ever bogging down. The best part is that it effortlessly provides a clean cut on the very first pass, savin...
From JohnDeere
We appreciate you taking the time to share your review. We're glad to have you as part of the John Deere family!
3.8 hrs won't start
Bought this at end of last year. Just drove it around getting uses to it. I used my old john deere tractor to mow the lawn and clean up the leaves. This year I changed the oil and checked it out completely. Put in new gas and drove it around a bit. Old tractor did all the clean up.finally moved my small lawn with it and put it away.went to start it and nothing but cranking.has 3.8 hrs on it Primed the carb. Still nothing nothing left to say will check back later
From JohnDeere
Thanks for letting us know. We appreciate the feedback.
No title
I've owned this mower for more than four years...very powerful, fast cutting machine. Easy to maintain when ethanol free 90 octane gas is used. It burn very clean and keeps fuel system clean.
From JohnDeere
That's what we like to hear!













Thanks for sharing your feedback of the Z530M ZTrak™ Mower. We appreciate you taking the time to leave a review.
