Graco Project Painter Plus Airless Paint Sprayer Interior Paint Project Kit



Items Included in this Collection



Item #320050 |
Model #257025
Sprays unthinned paint and a variety of other coatings
Adjustable pressure control to suit whatever your project demands
Great for indoor/outdoor DIY projects like fences, decks or sheds
Perfect for DIYers looking for a fast and easy alternative to brushes and rollers to quickly complete a number of household projects
Ideal for projects up to 5 gallons in size, allowing you to tackle a range of projects every year
Fully adjustable pressure control to give you ultimate control to spray paints or stains unthinned at any pressure
Flexible Suction Tube allows you to spray directly from a 1 or 5-gallon paint bucket
Supports up to 50 ft of paint hose to reach peaks or second stories without diminishing performance
Supports 10 TrueAirless Spray Tips giving you the flexibility to complete a number of projects with ease
General | |||
|---|---|---|---|
Collection/Series Name | Magnum Project Painter Plus | Pump Type | Piston |
Series Name | Magnum Project Painter Plus | Filter Type | 30-mesh |
Type | Stationary | Gun Trigger Type | 4-finger |
Power Source | Electric | Cup Fed | No |
Grade | Residential | Direct Syphon | Yes |
Use Location | Indoor/Outdoor | Spray Gun Material | Metal |
Airflow (CFM) | 0 | Material Flow Control | Yes |
Housing Material | Plastic | ||
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 13.6 | Minimum Fan Pattern Width (Inches) | 4 |
Direct Syphon Capacity | 1-5 gallon | Minimum Tip Size (Inches) | 0.009 |
Height (Inches) | 17.8 | Tip Size | 0.015-in |
Hose Length (Feet) | 25 | Tip Size Code | 515 |
Maximum Fan Pattern Width (Inches) | 10 | Weight (lbs.) | 12 |
Maximum Hose Length (Feet) | 50 | Width (Inches) | 11.1 |
Maximum Hose Length Capability (Feet) | 50 | Battery Amp Hours | 0 |
Maximum Tip Size (Inches) | 0.015 | Diameter of Hose Included | 1/4-in |
Features | |||
|---|---|---|---|
Actual Gallons per Minute | 0.24 | Pressure Rating (PSI) | 2800 |
Adjustable Fan Pattern Control | Yes | Pump Replaceable | No |
Adjustable Spray Pattern | Yes | Spray Gun Filter | Yes |
Battery(s) Included | No | Variable PSI | Yes |
Built-In Hose Swivel | No | Voltage (Volts) | 120 |
Cordless | No | Wheeled | No |
Engine Horsepower | 0.375 | Project Size | Medium |
Multi-Directional Spray | Yes | ||
Compatibility | |||
|---|---|---|---|
For Use with Stains | Yes | For Use with Walls | Yes |
For Use with Latex Paints | Yes | For Use with Floors & Ceilings | Yes |
For Use with Oil Paints | Yes | For Use with Woodworking Projects | Yes |
For Use with Doors | Yes | For Use with Furniture & Cabinets | Yes |
For Use with Acrylic Paints | Yes | For Use with Decking | Yes |
For Use with Lacquers | No | For Use with Fencing | Yes |
For Use with Water-Based Paints | Yes | For Use with Oil-Based Stains | Yes |
For Use with Elastomerics | No | Use with Material Flash Point (Degrees) | 100 |
For Use with Urethanes and Varnishes | Yes | For Use with Primer | Yes |
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | Safety Listing | ETL safety listing | |
Warranty | |||
|---|---|---|---|
Warranty | 1-year limited | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 31211900 | ||
Ratings may include incentivized customer reviews.
What Customers Are Saying
The paint sprayer is easy to use and delivers a smooth, even application of various paint types without thinning. It can cover large areas quickly, making it a time-saver for DIY projects. While the cleanup process requires some effort, most users find it manageable. A few isolated issues with clogging or leaks were reported, but overall the sprayer is considered an excellent value for home improvement tasks.
Customer review summary generated by AI, including incentivized reviews.Good Product, Bad Lowes service
I read good reviews about this product. I wanted it because I need to stain my new fence. I saw that I could get same day delivery on this item, so I secured a painter, and canceled work so I could make this happen. The product never arrived that day. I received a notice that it woulf be delivered the next day. I asked my painter to wait, he agreed. Next day nothing. 3rd day nothing. I filed a complaint. 4th day nothing. I called looking for the package and they promised the next day. 5th day no...
Verified Purchaser
Average Sprayer
This paint sprayer replaced my Wagner sprayer that I have had for years. After completing the prep, primer and paint process, the sprayer started out working well and then clogged easy. I used a pain that had a 2000 PSI minimum, and this sprayer goes up to 2800 PSI. The solution was filtering my paint and still adding a little water. However, it still clogged after a short period of use. If I would have used it as a continued spray, then the flow may have remained without clogging. In comparison...
From magnum.graco.com
Better than I ever could have imagined.
This is the second time I have bought a sprayer in 30 years. The old one was another brand and never worked well so I wrote off buying another sprayer for over a decade. I wish I had tried Graco years ago. I unpacked this machine, put it together and browsed over the instructions all in about 30 minuets. Put the pick up into a 5 gallon bucket of semi gloss exterior paint , turned it on , primed it and went to work in 5 minuets. The results? Fantastic! it was so easy and fast I could not believe ...
From magnum.graco.com
Light weight, simple user friendly instructions
I love this sprayer! I am completely satisfied and would recommend this to anyone wanting to tackle their diy projects. It is super easy to use and makes painting a breeze.
From magnum.graco.com
Velocidad increíble,Acabado profesional.
He tenido la oportunidad de probar el Magnum Project Painter Plus y, sinceramente, cambia por completo la perspectiva de lo que es pintar uno mismo. Si vienes de usar rodillo y brocha, esto es entrar en otra liga.
From magnum.graco.com
Best Sprayer Hands Down
I purchased my sprayer about a month ago and when the weather finally cooperated, I got to use it to paint the outside of my house. I have never used a paint sprayer before so I am a newbie. But I can say, it was very easy to setup and use. The directions were very clear and easy to understand. I would suggest watching several video's to get some well needed tips. I would recommend this sprayer for the do-it-yourself person. It's plenty of sprayer for painting the outside of your home and ...
From magnum.graco.com
Not dependable
I bought two weeks ago and used it this weekend. I followed all instructions before using. It repeatedly stopped o had to clear it then the switch or motor stopped working. Had to paint entire fence by hand.
From magnum.graco.com
Hi Peterbilt, We’re sorry to hear about the trouble you experienced with your Magnum Project Painter Plus Electric TrueAirless Sprayer and that it did...
Graco mini airless
I have a 30 year old Graco with a Baldor motor, still working great for bigger jobs. I bought this little one for some small jobs at home. It works good, nice soft spray great for beginners. Start up has a lot of steps, seems like it has a lot of unnecessary ones
From magnum.graco.com
Excellent machine made it tolerable
Works perfectly. Much faster than a roller or brush. Takes a couple times to get the sequence of priming down, but it's not hard. Cleanup with a hose connection is easy. We wasted a lot of paint on the first time we primed, just because we didn't trust ourselves, but later got way more efficient. I suggest starting with a little thinner paint, though this thing will certainly spray thick stuff. My wife loves using this thing. Definitely do good prep, cause it can blow your tape off the wall e...
From magnum.graco.com
Hello Ihatepainting, Thank you for the outstanding review! We’re thrilled to hear that the Magnum Project Painter Plus Electric TrueAirless Sprayer w...
lowes is going to policy themselves out of busines
Lowe's has more policies than one can keep up with, they burry them in foolish locations, with today's technology if there is a strange policy maybe they can have a pop up at checkout, self checkout that is because finding employees at checkout is pretty impossible. now to the employees and their knowledge of policy, well it appears they read as far as they wish and stop, if they read and understand the policy in its entirety they would see the bad attitude they have is their own doing and that...

Hello Brent6511, Thank you for taking the time to share your detailed feedback on the Magnum Project Painter Plus Electric TrueAirless Sprayer. We’re ...
