Description:
The push button switch station consists of three switches, one is a momentary red push button switch, one is a momentary green switch and a emergency stop switch.
Can be widely used to control the electromagnetic starter, contactor, relay and other automatic control electric circuits.
Comes with quick connect terminals to allow for fast connections.
Specification:
Material: PC
Red Green Button: Momentary
Emergency Stop Switch: Self-Locking
Contact Type: NO NC
Button Color: Red, Green
Ith: 10A; Ui: 440V
Screw Hole Dia: 4mm / 0.16"
Button Hole Size: 22mm/ 0.86"
Outlet Hole Diameter: 20mm/ 0.79"
Hole Distance(center to center): 115 x 54mm/ 4.53" x 2.13" (L*W)
Total Size (Approx.): 150 x 71 x 95mm / 5.91 x 2.8 x 3.74" (L*W*T)
Package Content:
1 x Push Button Switch Station
