Prime-Line 3.93-in Surface mounted Sliding Patio Door Handle
Item #487347 |
Model #C 1280
Used on a variety of patio doors
Mounting holes are 3-15/16 in on center
Reversible for right or left handed doors
Use Prime-Line part number E 2145 to make the handle set keyed
Hardware included, and hand tighten only, do not use a power drill
Features offset handle that can be reversed by unscrewing the screws in the back and switching the D handle
INSTALLATION NOTES – Includes two sets of installation screw lengths to accommodate varied door thickness and fasteners should be hand tightened only, and see model C 1317 for the centered lever version
A Phillips head screwdriver is required for installation
NOTE: Locking cylinder is optional (Not included)
General | |||
|---|---|---|---|
Color/Finish Family | White | Package Quantity | 1 |
Hardware Finish | White | Package Contents | 1 inside pull; 1 outside pull; 1 set of installation fasteners, 10-24 threading |
Type | Handle | Handle Type | Surface mounted |
Material | Zinc die-cast | Handing | Reversible |
Dimensions | |||
|---|---|---|---|
Center to Center Length (Inches) | 3.93 | ||
Features | |||
|---|---|---|---|
Latch Style | Hook | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | No | ||
Warranty | |||
|---|---|---|---|
Warranty | 1-year limited | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 31161600 | ||
Check out the Best Selling Sliding Patio Door Handles on Lowes.com
Ratings may include incentivized customer reviews.
Sent wrong part
The handle interferes with the molding. Why would I want the handle next to the molding? I can't even install it. The picture doesn't match what I got. I can't flip the handle due to the offset lock
Verified Purchaser
READ THIS BEFORE YOU THINK IT DOESN'T FIT
We bought this to replace our current one which broke, using the measurement from screw to screw (3 and 5/16"). But when we went to install, the lock switch doesn't line up with the existing holes on the door, as several reviewers have pointed out. But if you go to the Prime Line site itself and look at this product, you see Lowes and HD omitted a very important detail: "NON-HANDED CONSTRUCTION – The sliding door handles can be used on either right- or left-handed doors by reversing the handle o...
Needing to replace for a 3rd time
We have now bought 2 of these. The first one lasted one year and the second one lasted 5 years. Our downstairs sliding door, which has gotten a lot more use; has never been replaced in the 16 years we have owned the house.
Nice handle - buy the lock/latch separately
This is a pretty and ergonomically comfortable handle. Unfortunately, the latching mechanism was not included so we needed to use half of the old handle and half of the new one. Looks like the lock/latch is sold separately and we may need to drill a new hole for the strike plate. We had a lack of time so it will stay as it is which is fine for the moment.
Verified Purchaser
Locking mechanism off center
All descriptions fail to mention the locking mechanisms is off center. Measurements should be included for this important feature
Verified Purchaser
Solved the big problem.
Wanted a handle on both sides, this did the trick/lock did not work had to install a security bar.
Verified Purchaser
Sliding door handle replacement
It is easy to install. I have installed two of since we put the sliding door. Keep the rollers on the well lubricated.
Verified Purchaser
