Genova Schedule 80 PVC pressure pipe, 20' plain-end, gray. Made from polyvinyl chloride for pressure piping, this Schedule 80 pipe is rated for a maximum working pressure of 400 psi at 73 F. Available sizes: 1/2' x 20' (PN 300055, OD 0.84', ID 1/2') 3/4' x 20' (PN 300075, OD 1.05', ID 3/4') 1' x 20' (PN 300105, OD 1.32', ID 1') 1-1/4' x 20' (PN 300115, OD 1.66', ID 1-1/4') 1-1/2' x 20' (PN 300125, OD 1.90', ID 1-1/2') and 2' x 20' (PN 300225, OD 2.37', ID 2'). Plain ends allow connection with couplings or fittings. Packaged as a single unit the 2' x 20' variant ships in a box 40' x 40' x 24' with a gross weight of 19.19 lbs. Perfect for pressure system installations requiring the strength and dimensions of Schedule 80 PVC.
Schedule 80 PVC construction provides enhanced wall thickness and pressure capacity
20' plain-end length reduces the need for joints on long runs
Maximum working pressure of 400 psi at 73 F for rated pressure applications
Available in sizes from 1/2' to 2' to suit various piping needs
Gray finish for easy identification in mechanical and industrial systems
Plain ends designed for use with couplings or fittings during installation.
Manufacturer part number 300225 identifies the 2" x 20' variant.
Outer and inner diameters provided by size to assist with planning and fittings selection.
Sold individually; 2" x 20' unit ships in box 40" x 40" x 24" with a gross weight of 19.19 lbs.
