CRAFTSMAN Z5800 54-in 24 -HP V-twin Gas Zero-turn riding lawn mower
Item #2593138 |
Model #CMXGNAM211704
Powerful engine: Powered by a reliable 24 HP Kohler® 7,000 twin-cylinder engine
Adjustable lap bar: Easy to operate 3-way adjustable lap bar allows you to work more efficiently
Comfort: Rubber foot pad provides a smoother ride with less vibration
Increased traction control: 20x8/11x6 Turf Master® tires offer excellent traction without damaging your yard
Durable: 54-in stamped steel deck holds up against tough obstacles.
Cut-and-sew seat: High-back seat provides comfort and support to make sure the job gets done right
Warranty: 3-year limited product manufacturer warranty and 5-year frame warranty
Engine disclaimer: Engine power ratings are as certified by the engine manufacturer as actual operating power may vary
See the Parts and Attachments section below and the parts diagram in the images section for all the correct CRAFTSMAN® mowers parts and accessories
General | |||
|---|---|---|---|
Blade Engagement Type (PTO) | Electric | Power Source | Gas |
Deck Type | Stamped | Seat Type | High-back |
Drive Type | Rear wheel drive | Series Name | Z5800 |
Engine Type | V-twin | Start Type | Turn key start |
Number of Deck/Anti-Scalp Wheels | 3 | Transmission Type | Dual hydrostatic |
Oil Filter Type | Spin-on | Type | Zero-turn riding lawn mower |
Dimensions | |||
|---|---|---|---|
Cut Width (Inches) | 54 | Minimum Cutting Height (Inches) | 1.5 |
Engine Oil Capacity (oz.) | 65 | Overall Length (Inches) | 85 |
Front Wheel Size | 11-in | Overall Width with Deck (Inches) | 62 |
Fuel Capacity (Gallons) | 3.5 | Rear Wheel Size | 20-in |
Maximum Cutting Height (Inches) | 3.75 | Weight (lbs.) | 865 |
Features | |||
|---|---|---|---|
Ammeter | No | Engine Series | Kohler 7,000 |
Bagger Capable | Yes | Front Axle | Fabricated steel |
Bagger Included | No | Grease Fittings | Yes |
Charger Included | No | Headlight(s) | No |
Cruise Control | No | Lowe's Exclusive | Yes |
Deck Gauge | 13 | Maximum Forward Speed (MPH) | 7 |
Discharge Location | Side | Maximum Reverse Speed (MPH) | 3.5 |
Engine Brand | KOHLER | Model Description | Craftsman 54-in with Kohler ZTR |
Engine Displacement (Cu. Centimeters) | 724 | Mulching Capable | Yes (kit sold separately) |
Engine Horsepower | 24 | Number of Blades | 3 |
Engine Oil Included | Yes | Operator-Controlled Mow-in-Reverse | No |
Compatibility | |||
|---|---|---|---|
Attachment Compatible | Rear | Recommended Yard Size | 2 to 3 acres |
Matching Bagger (Item #) | 1136141 | Replacement Belt OEM Part Number | 954-04329A |
Matching Mulch Kit (Item #) | 5216233 | Replacement Blade OEM Part Number | 742P05086 |
Recommended Terrain Type | Flat with obstacles | ||
Warranty | |||
|---|---|---|---|
Warranty | 3-year limited | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 21101700 | ||
Check out the Best Selling Riding Lawn Mowers on Lowes.com
Ratings may include incentivized customer reviews.
What Customers Are Saying
The mower is generally well-received, with customers praising its performance, maneuverability, and power. It cuts grass efficiently and provides a smooth, even cut, even on inclines. The mower is described as having a sturdy construction, reliable engine, and easy-to-use controls. However, some customers have reported issues with the transmission, flat tires, and the blade flying off. A few users also noted the lack of an hour meter and fuel gauge as drawbacks. Overall, the mower appears to be a capable and well-designed zero-turn mower that meets the needs of many homeowners with medium to large-sized yards.
Customer review summary generated by AI, including incentivized reviews.Customer Sentiment
Good Zero Turn mower.
Im still getting use to cutting with it. First zero turn i ever own.
Verified Purchaser
Right Tractor for the Right Job
Everything I Expected from Craftsman. 24 horsepower, quick start, excellent on fuel consumption with accessories for every task. Mower runs strong and easier to operate than expected.
Verified Purchaser
Very good mower
It works very well
Verified Purchaser
Check it over
Got it home, saw no owners manual. Oh well, just downloaded it from online. Went out the next morning to try it out. Filled it with gas. Called for 1.9 quarts of oil. Let it settle,checked the dipstick, too much, went to drain a little bit out found out the oil plug was only in one turn. It was already leaking out.. If I wouldn’t have put too much in and went to drain some back out, I would’ve never saw that and I’m sure that plug would’ve fell out and I would’ve ruined that motor. Wouldn’t. st...
no traction
the mower, everything seems good except haven't been able to lower the trimmings gaurd and on very little inclined rear end slides loses traction, been really pondering about returning and try something different or just invest in maybe some different tires idk, but haven't had it long. isn't going to work at my house in its current setup
We're sorry to hear about the issues you are experiencing with your CRAFTSMAN equipment. We recommend contacting one of our Authorized Service Ce...
Great mower
Pick up from the store was easy. Love to run this mower!!
Verified Purchaser
Junk
Leaves a streak between Left and Middle blades. Have sharpened, put new blades, and taken to a shop for correction. None of these have fixed the issues. If you’re wanting a mower, I suggest looking elsewhere. The only reason I gave 2 stars is because the motor is strong and does not bog down.
From craftsman.com
Hello Nick Dale and thank you for taking the time to provide your feedback. I am sorry that you had a negative experience with CMXGNAM211704 CRAFTSMAN...
