Brixwell PHNW8X8MBL Back-To-Back Tubular Pull Handles Without Metal Washers 1/4 In To 1/2 In Glass Thickness 8 In Center-To-Center Matte Black Finish

Back-To-Back Tubular Pull Handles Without Metal Washers 1/4" To 1/2" Glass Thickness 8" Center-To-Center Matte Black Finish are designed for glass door applications where back-to-back operation and direct glass mounting are required, such as shower enclosures and interior glass doors. The pull handles are manufactured from brass and feature a tubular construction with a 3/4" Diameter and a Tube Thickness of 1.5mil, providing defined grip spacing and consistent shape across the handle length. The mounting configuration is Glass Mount Back To Back and is intended for use with Monolithic Tempered Glass panels. The handle assembly supports Glass Thickness from 1/4" to 1/2" and installs without metal style washers, allowing direct alignment at the glass surface. Handle positioning is based on a fixed 8" Center-To-Center, supporting accurate alignment during installation or replacement. Installation requires a Hole Diameter of 1/2" and uses a 1/4"-20 Thread Size fastening system to secure both handles through the glass panel. The design provides a measured Projection From Surface of 2-1/2", allowing defined hand clearance while maintaining a compact profile on the glass door. Plastic Washers For Glass Protection are included to reduce direct contact between metal components and glass during mounting. The Matte Black Finish provides a uniform dark surface appearance that blends with coordinated glass door hardware. Installation Instructions- 1) Mark the 8" Center-To-Center on the glass panel and confirm glazing thickness compatibility. 2) Drill 1/2" diameter holes through the monolithic tempered glass. 3) Place the plastic washers on both sides of the glass at each mounting point. 4) Align the pull handles on opposite sides of the glass panel in a back-to-back position. 5) Insert the 1/4"-20 threaded fasteners and tighten evenly to secure the handles without overtightening.
