Each Remcon relay has a built-in transformer for unit control. Each relay in the system operates independently from and has no effect upon other relays. Install as little as one relay and operate it with as many switches as is desired.
Momentary switch type relay (3 wire)
Switches AC power on and off using low voltage control circuit
Built in transformer, no step down transformers necessary
Single relay can be controlled by multiple switches and multiple relays can be controlled by single switch
Light #22 cable can be used to control relay instead of Romex or armored cable – significant time and cost savings
AC voltage from 105 to 125 V
AC current up to 6.5 A (1/4 HP maximum motor load at 120 V)
Frequency: 60 Hz
Safe control switching: 10 VDC maximum and 10 mA maximum
