Honeywell Home RLV4305A 5-2 day Programmable Thermostat
Item #459230 |
Model #RLV4305A1000/E1
For use with electric baseboard heat (120-240 volt), convectors and fan-forced heaters
5-2 Day programming - separate programs for the weekdays, Saturday, and Sunday
2-Wire installation with non-polarized connection
Temporary program override
Battery-free backup retains programming in the event of a power outage
TRIAC silent switching
Backlit display
General | |||
|---|---|---|---|
Series Name | RLV4305A | Wiring Type | 2-wire |
Type | Thermostat | Heating Only | Yes |
Shape | Rectangle | Cooling Only | No |
Display Type | Digital | Temperature Displayed | Current room temperature |
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 1.5 | Width (Inches) | 4.5 |
Height (Inches) | 4.75 | ||
Features | |||
|---|---|---|---|
Auto System Change from Heat to Cool | No | Multi-Stage Heating | No |
Backlit Display | Yes (always on) | Optional Battery-Free Operation | Yes |
Built-In Z-Wave | No | Program Periods per Day | 4 |
Daylight Savings Time Ready | No | Remote Control Included | No |
Early-Start Comfort Function | No | Single-Stage Cooling | No |
Filter Monitor | No | Single-Stage Heating | Yes |
High/Low Desired Temperature Limits | No | Temporary Vacation Override | Yes |
Hold Temperature Button | No | Touch Screen Programming | No |
Hub Required | No | Voice Controlled | No |
Multi-Stage Cooling | No | Program Settings | 5-2 day |
Compatibility | |||
|---|---|---|---|
App Compatibility | No | Works with Amazon Alexa | No |
Bluetooth Compatibility | No | Works with Android | No |
Compatible with Central Air Conditioning | No | Works with Apple HomeKit | No |
Compatible with Heat Pump (No Aux.) | No | Works with iOS | No |
Compatible with Heat Pump (No EM) | No | Works with SmartThings | No |
Compatible with Heat Pump (With Aux.) | No | Works with the Google Assistant | No |
Compatible with Heat Pump (With EM) | No | Use with Electric Baseboard 120V-240V | Yes |
Compatible with Hot Water | No | Use with Floor/Wall Furnace 24V or 750mV | No |
Compatible with Steam or Gravity | No | Use with Volt Gas Fireplace 24V or 750mV | No |
Compatible with Warm Air Furnace | No | Use with Pellet Stove for mV Thermostats | No |
Wi-Fi Compatibility | No | ||
Warranty | |||
|---|---|---|---|
Warranty | 1-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | No | Safety Listing | UL safety listing |
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 41112200 | ||
Check out the Best Selling Programmable Thermostats on Lowes.com
Ratings may include incentivized customer reviews.
not working after only 13 months
I bought 8 units 11/24 and 4 of are not working after only 1 month after the warranty expired, I’m hoping the manufacturer can help with a solution I can’t afford to replace them
Perfect product at a fantastic price
Super easy instructions and took less than 2 minutes to install. Backlit LCD screen is very nice for not having to turn on a light to see what the temperature is. It operates perfectly
Verified Purchaser
Easy install for electric heat only
easy install, haven't programed yet. I had to go back for a programable that was for electric heat only with 2 wires. There are minimal choices for the option to program with baseboard. I had the same one for 10+ years that got fried during a power outage. Reading other reviews I was a bit worried to purchase this one again, but as I said not many options for wat I needed. This was affordable, the other not so much.
Verified Purchaser
Works then burns out
I have these installed in all three bedrooms in which each thermostat controls a single cadet wall fan heaters at 1000w and 1500w both at 120v. Each thermostat is on its own 15amp breaker with 12/2 wire. The thermostat in my master bedroom kept the fan heater running constantly over the last couple days with a minimal change in temperature reading on the thermostat. Today, the heater shut off and I pulled off the thermostat and it had overheated to a degree where it melted the wire nuts and wire...
Hi Garrett, we are sorry to hear about this. We recommend you having your electrician checking the electrical ratings. - Maria
Lasted Almost 3 years
Lasted almost three years, then stopped working and shows error codes with no explanation of what they mean. I spent 45m on the phone with support and even Honeywell couldn't tell me what the errors "2.5" "8.4" and "11.9" mean.
Hi, thank you for bringing this to our attention. Those are boot up codes that are shown if the minimum load requirement or voltage are not met. Plea...
Works great.
Looks good, works great, easy to program.
Verified Purchaser
Only lasted 1 yr 6 months
stopped working shortly after the warranty expired, I recommend finding another product.
Hi Tim, we are truly sorry to hear about this. This is not what you should expect and we will be happy to help troubleshooting to verify if this is s...
2 Questions
2 Questions
1
Answer
1
Answer
Hi marcia, we are sorry to hear about this. We recommend you to contact your electrician to check voltage, wattage and amperage. You can contact our ...
