Honeywell Home RTH6360D 24-Volt 5-2 day Programmable Thermostat
Item #883698 |
Model #RTH6360D1002
Here are some similar items...
The RTH6360D offers flexible 5-2-day or 1-week programming so you can set your own schedule for comfort and energy conservation
Smart Response Technology learns how long it takes to achieve the right temperature at the right time and automatically runs your system to get to your desired temperature when you want it
Backlit LCD display shows current room temperature and set point temperature simultaneously
Features auto changeover between heat and cool and reminder alerts for low batteries and filter changes
Program is retained in memory in the event of a power outage so you can be confident your comfort stays intact
The UWP mounting system, included mounting hardware, and quick install guide can have your thermostat up and running quickly
Requires 2 AA batteries (not included)
Compatible with: forced air (gas, oil or electric), hot water and steam, and heat pumps with electric backup
Does not work with electric baseboard heat (120-240V)
General | |||
|---|---|---|---|
Series Name | RTH6360D | Wiring Type | 2-wire |
Type | Thermostat | Heating Only | Yes |
Package Quantity | 1 | Cooling Only | Yes |
Shape | Rectangle | Temperature Displayed | Current and setpoint/desired temperature |
Display Type | Digital | ||
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 1.08 | Width (Inches) | 5.36 |
Height (Inches) | 3.86 | ||
Features | |||
|---|---|---|---|
Auto System Change from Heat to Cool | Yes | Multi-Stage Heating | Yes |
Backlit Display | Yes (motion activated) | Optional Battery-Free Operation | Yes |
Batteries Included | No | Program Periods per Day | 4 |
Built-In Z-Wave | No | Remote Control Included | No |
Daylight Savings Time Ready | Yes | Single-Stage Cooling | Yes |
Early-Start Comfort Function | Yes | Single-Stage Heating | Yes |
Filter Monitor | Yes | Temporary Vacation Override | Yes |
High/Low Desired Temperature Limits | Yes | Touch Screen Programming | No |
Hold Temperature Button | Yes | Voice Controlled | No |
Hub Required | No | Voltage (Volts) | 24 |
Multi-Stage Cooling | Yes | Program Settings | 5-2 day |
Compatibility | |||
|---|---|---|---|
App Compatibility | No | Works with Amazon Alexa | No |
Bluetooth Compatibility | No | Works with Android | No |
Compatible with Central Air Conditioning | Yes | Works with Apple HomeKit | No |
Compatible with Heat Pump (No Aux.) | Yes | Works with iOS | No |
Compatible with Heat Pump (No EM) | Yes | Works with SmartThings | No |
Compatible with Heat Pump (With Aux.) | Yes | Works with the Google Assistant | No |
Compatible with Heat Pump (With EM) | Yes | Use with Electric Baseboard 120V-240V | No |
Compatible with Hot Water | Yes | Use with Floor/Wall Furnace 24V or 750mV | Yes |
Compatible with Steam or Gravity | Yes | Use with Volt Gas Fireplace 24V or 750mV | Yes |
Compatible with Warm Air Furnace | Yes | Use with Pellet Stove for mV Thermostats | Yes |
Wi-Fi Compatibility | No | ||
Warranty | |||
|---|---|---|---|
Warranty | 1-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | No | Safety Listing | UL safety listing |
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 41112200 | ||
Check out the Best Selling Programmable Thermostats on Lowes.com
Ratings may include incentivized customer reviews.
What Customers Are Saying
The product has a mix of positive and negative feedback. On the positive side, it is easy to install and program, with useful features like temperature presets. However, it has issues with inconsistent temperature readings, poor temperature control, and reliability problems, with many reports of the thermostat failing within a year. Programming and settings can also be confusing, especially for heat pump systems. Additionally, the requirement for batteries despite a wired connection is a drawback, as the batteries can corrode over time.
Customer review summary generated by AI, including incentivized reviews.only requires 2 wires: power & neutral
so, i was shopping because my not very old looking thermostat had a low battery notification... but too late. the batteries corroded & i lost usability. i looked to see if either of the two major players had the same unit (then I could skip wiring & the unknown - just pop in two batteries on a non-damaged circuit card) and attach to wall piece. Nope. One place had it, and claimed they could get it to me by tomorrow, but then i'd have to investigate with trustpilot and such. I considered oth...
Not bad for a cheap programmable thermostat
This is my second thermostat, the first one I purchased was faulty and caused the heating system to turn on at all times, even when the batteries were removed from the thermostat. I left a one-star review, which suspiciously never showed up. I figured it was a dud, so I returned it and purchased another one of the same model, because I wanted a simple programmable but not smart thermostat. So far it is doing its job, but it's a little quirky. When the temperature reaches close to the set point i...
Verified Purchaser
Will not stick to programmed schedule
It will not hold a programmed setting for longer than 8 hours. Set sleep time at 8:30pm with temp at 67. Wake time is 6:30am with temp at 72. At 4:30am the heat is on, warming to 72 and says it is "following schedule". So by 5 am I am laying in bed sweating. Have tried to reprogram it with the same result. Check the programming settings, still set for 67 degrees from 8:30pm to 6:30am. But at 4:30 the screen shows the scheduled temp to be 72. So last night tried setting a temporary hol...
Verified Purchaser
Easy to read and program.
I bought this to replace an almost 20 year old thermostat that was almost impossible to program. This new unit is a dream to program for the whole week an works perfectly on automatic. I will say that I paid for professional installation.
Verified Purchaser
Awesome Thermostat!
I bought this product 3 or 4 years ago now to replace a failing AprilAire thermostat from 2002 (when my house was built) on the second story. This thermostat has been working like a charm ever since. Therefore when the second thermostat on the first story of my house failed last year, I decided to get this exact same one. A few things I love about these thermostats: - The modern sleek design compared to the old dated looking ones. - The backlit display makes it very easy to read and works v...
From resideo.com
This "new" thermostat had been opened and returned
This 2 star review is not necessarily for Honeywell, (unless they actually sent this returned unit to Lowe's). It's Friday evening before Christmas weekend and our thermostat malfunctioned. I ordered a new online for store pickup and rushed to the store. Got home and opened the box and discovered that the clear peel-off protective sleeve was removed and laying in the bottom of the box and the screws/anchor package was missing. Also, in addition to the manual for this thermostat there was a m...
Verified Purchaser
Hi JimInAlabama, we are truly sorry to hear about this. This is not what you should expect. We are happy to hear that the thermostat is working fine....

Heats all the time, even when off
When the thermostat is off it calls for heat. Heat runs until you unplug the unit from the wiring plate. Not only the heat pump but the aux heat. Tested with a multimeter, there is conductivity between R and O/B, also R and W, even when the unit is off, and EVEN WITH THE BATTERIES REMOVED. On the upside, it's pretty.
Hi John, we apologize you're experiencing this with your unit. Please feel free to get in touch with us for support at 800-633-3991 and we can ta...

It was a very easy installation. You can't go wrong with Honeywell. It is friendlier to use than a smart thermostat. We will not be purchasing another smart thermostat ever again. In less than five years, we have already gone thru two units by different vendors. They units are very finicky and break right shortly after the manufacturer's warranty expires. How convenient.
Verified Purchaser
Temperature not reading correctly
My furnace is gas forced air. My old LUX thermostat died. I set this Honeywell to the same heating temperature of 68F. I noticed the room is hotter than usual. I look at my indoor thermometer and it says 71F but this Honeywell thermostat says 68F. So now i have to set the thermostat to 65F to get my 68F.
Hi David68, we are sorry to hear about this. Our thermostats use the ambient and radiant temperature for the indoor temperature display, so this read...

thermostat
This thermostat is about useless for homeowners who wants to change their old thermostats to a new programmable one you can't mount them to your walls without having to buy a mounting plate at an extra cos? We just bought two of these thermostats 5-2 DAY PROGRAMMABLE THERMOSTAT RTH6360 5-2 DAY PROGRAMMABLE THERMOSTAT to change our old ones out but we couldn't mount them do to no mounting bracket or plate. So we had to take them back and get our money back wasn't to happy about wasting gas to ...
From resideo.com
Hi tenpin, the wall mount is included with the thermostat. If your missing pieces on your product or something seems to be broken, please do take it t...
