Graco TC Pro Battery Handheld Airless Paint Sprayer
Item #961046 |
Model #17N166
Optimal for touchup and small jobs requiring ultimate portability
Powered by DeWalt's 20-Volt MAX XR Lithium-ion Battery
SmartTip technology provides a superior finish with less pressure
Designed for Property Maintenance Pros, Remodelers and PRO Painters who demand the highest power and performance
Ideal for jobs up to 2 gallons in size, allowing you tackle a range of projects every year
Powered by DEWALT 20V Lithium Ion battery to keep you moving freely around the jobsite
Triax Triple Piston Pump built from durable carbide provides years of reliability
ProControl II adjusts pressure from 0 psi to 2,000 psi giving you the spray at any speed with less overspray
SmartControl allows for precision pressure control that delivers a consistent spray fan without pressure fluctuations
General | |||
|---|---|---|---|
Gun Trigger Type | 2-finger | Housing Material | Plastic |
Spray Gun Material | Plastic | Type | Handheld |
Cup Fed | Yes | Filter Type | 60-mesh |
Direct Syphon | No | Grade | Residential |
Material Flow Control | Yes | Pump Type | Piston |
Cup Material | Plastic | Power Source | Battery |
Airflow (CFM) | 0 | Use Location | Indoor/Outdoor |
Collection/Series Name | TC Pro | Series Name | TC Pro |
Dimensions | |||
|---|---|---|---|
Maximum Hose Length Capability (Feet) | 0 | Depth (Inches) | 14 |
Maximum Cup Capacity | 1-quart | Height (Inches) | 10.5 |
Minimum Tip Size (Inches) | 0.008 | Weight (lbs.) | 5.25 |
Maximum Fan Pattern Width (Inches) | 10 | Width (Inches) | 5 |
Minimum Fan Pattern Width (Inches) | 4 | Hose Length (Feet) | 0 |
Maximum Hose Length (Feet) | 0 | Maximum Tip Size (Inches) | 0.016 |
Tip Size | 0.014-in | Battery Amp Hours | 2 |
Tip Size Code | 514 | ||
Features | |||
|---|---|---|---|
Actual Gallons per Minute | .2 | Project Size | Small |
Built-In Hose Swivel | No | Voltage (Volts) | 20 |
Multi-Directional Spray | Yes | Adjustable Spray Pattern | Yes |
Spray Gun Filter | Yes | Engine Horsepower | .25 |
Variable PSI | Yes | Cordless | Yes |
Adjustable Fan Pattern Control | Yes | Wheeled | No |
Pump Replaceable | Yes | ||
Compatibility | |||
|---|---|---|---|
For Use with Latex Paints | Yes | For Use with Decking | Yes |
For Use with Oil Paints | Yes | For Use with Fencing | Yes |
For Use with Oil-Based Stains | Yes | For Use with Acrylic Paints | Yes |
For Use with Primer | Yes | For Use with Lacquers | No |
For Use with Urethanes and Varnishes | Yes | For Use with Water-Based Paints | Yes |
For Use with Doors | Yes | For Use with Elastomerics | No |
For Use with Walls | Yes | Use with Material Flash Point (Degrees) | 100 |
For Use with Floors & Ceilings | Yes | For Use with Stains | Yes |
For Use with Woodworking Projects | Yes | Compatible Battery Type | Lithium ion (Li-ion) |
For Use with Furniture & Cabinets | Yes | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | Safety Listing | ETL safety listing | |
Warranty | |||
|---|---|---|---|
Warranty | 1-year limited | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 31211900 | ||
Check out the Best Selling Airless Paint Sprayers on Lowes.com
Ratings may include incentivized customer reviews.
What Customers Are Saying
This paint sprayer received mixed reviews. Many users found it easy to use, clean, and portable, with good coverage and finish quality. However, a significant number reported issues with durability and reliability, such as pump failures and clogging, even with proper care. Some felt the sprayer was overpriced given the performance. Thorough preparation and cleanup are important due to significant overspray. The sprayer may work well for smaller projects, but has reliability concerns that make it risky for larger or more demanding jobs.
Customer review summary generated by AI, including incentivized reviews.On Par with Other Reviews
I’ve used my TC PRO 3 times and I’m a bit concerned about the sound of the pump. It changes “tone” while spraying suggesting that there’s a slight interruption in flow and it shows. This is my second Graco and like my other, it uses too much paint and there is no way to slow it. Overall, it’s not bad, but at this point, I probably wouldn’t recommend to others to buy. I will continue to use and provide honest feedback.
From magnum.graco.com
Fast setup, easy clean up, perfect sprayer
I was a bit intimidated to use this sprayer. I own the Magnum X5 which take a bit to set up and prime but this little gem is quite easy to use and very easy to clean. I used it indoors for base boards and door trim using a Graco FFLP214 Fine Finish Low Pressure RAC X Reversible Tip. I had pressure dialed down to 2 out of 10. It worked really well and the clean up was very easy. I'm going to try it on some exterior doors next. I'm so happy with this purchase!
From magnum.graco.com
Amazing Sprayer
Amazing Sprayer! Lightweight even when full and using a 5-6AH battery. I highly recommend the 42oz cup and liners, as it can spray 1qt of paint very quickly. The only downside is having to refill the liners, but this is far outweighed by the conveniance of not having to deal with a paint hose and heavy sprayer. Im also a woodworker, so this sprayer will save me time applying stain and polyurethane! Well worth the $!
From magnum.graco.com
This is the best sprayer gun I’m so happy is excellent
From magnum.graco.com
TC Pro review
Bought this model to spray trim, doors and cabinetry. I have used HVLP guns and was dissatisfied with their performance when shooting latex paints. The TC Pro sprayed Sherwin Williams Emerald Enamel without thinning nicely using a FF312 tip. It does go thru paint quite quickly and requires frequent refilling of the 1 quart container, but this isn't a huge issue. Biggest gripe is cleaning the gun out after use. Would like to see some type of adapter so that a continuous supply of water could...
From magnum.graco.com
Works like a dream!
Works like a dream! Do yourself a favor and keep it very clean. Should last for years!
From magnum.graco.com
This is the second cordless sprayer that I have purchased and I've got to say it is such a time saver, easy to clean and always provides a fantastic finish.
From magnum.graco.com
Awesome Gun
Wow just Wow! This paint gun is awesome, it cuts the job time down to half if not more. I did buy a couple of the bigger pain holders so I could paint and my wife could fill the extra one. Just switch them out when empty and keep on rocking it, even with bigger jobs!
From magnum.graco.com
Coming with the cheap carrying bag
It came with the cheap carrying bag. Considering the price level, that bag must be compatible with the product level
Verified Purchaser
easy to use
I have 3 Graco paint machines on a 24 unit apartment home project this particular paint sprayer being untethered makes it an easier choice for touching up and smaller task.
From magnum.graco.com
50 Questions
5
Answers
2
Answers
1
Answer
1
Answer
1
Answer
1
Answer
1
Answer
1
Answer
1
Answer
1
Answer
Hello Takeadoe, Thanks for taking the time to share your experience with the TC Pro Cordless. If you have any concerns, please call our Tech Support t...
