MRCOOL DIY 5th Gen ENERGY STAR Single Zone Ductless Mini Split + Accessories Collection
Collection Items
SUCCESSWhen should I expect to get my items?
See availability by item
View Lower Price In CartWhen we price an item lower than the manufacturer's suggestion, we can only show that price in cart.
Item #6633412 |
Model #DIY-09-HP-WM-115D25O
Energy Star certified 23.6 SEER2, 11.5 HSPF
Easy DIY installation: pre-charged R-454B 25ft quick connect line doesn't require special tools, equipment, or training
Designed to efficiently heat and cool a single 350 Sq Ft room
SmartHVAC app: wifi control - compatible with amazon Alexa and Google assistant - you can control your DIY anywhere with your apple or android smart device and an Internet connection
Variable-speed DC inverter compressor technology cuts operating costs
Low ambient cooling: cooling down to 5F this feature makes the Mrcool DIY the ideal system for computer server rooms, greenhouses, and any other application that requires cooling all year
Gold fin condenser corrosion resistant - live on the coast, but don’t worry, our condenser is built to resist long-term corrosion
5-year parts warranty and 7-Year compressor
Follow me-feature, dehumidifying operation, auto mode, louver position memory, and sleep mode
General | |||
|---|---|---|---|
Refrigerant Type | R-454B | Control Type | Dimmable LED |
Number of Tons | .75 | Series Name | DIY 5th gen Energy Star |
Application | Heating/Cooling | Color/Finish Family | White |
Type | Quick connect (DIY) | Manufacturer Color/Finish | White |
Filter Type | Nylon | Mounting Location | Wall |
Dimensions | |||
|---|---|---|---|
Zone Capacity | 1 zone | Line-set Connection Size | 1/4-in x 3/8-in |
Air Handler Depth (Inches) | 7.44 | Depth (Inches) | 11.93 |
Compressor Depth (Inches) | 11.93 | Height (Inches) | 21.85 |
Air Handler Height (Inches) | 11.69 | Weight (lbs.) | 65.48 |
Compressor Height (Inches) | 21.85 | Width (Inches) | 30.12 |
Air Handler Width (Inches) | 31.57 | Amperage | 20 |
Compressor Width (Inches) | 30.12 | Cord Length (Feet) | 25 |
Line-set Length | 25-ft | Maximum Coverage Area (Sq. Feet) | 400 |
Features | |||
|---|---|---|---|
Full Load Amperage Requirement (Amps) | 20 | Automatic Shut-Off | Yes |
Hub Required | No | Cooling BTU Rating (BTU) | 9000 |
Annual Fuel Utilization Efficiency % (Percentage) | 0 | Fan Only Option | Yes |
Decibel Rating (Lowest Setting) | 18 | Heating BTU Rating (BTU) | 10000 |
Decibel Rating (Highest Setting) | 43 | Low Voltage Compensation | Yes |
Quiet Mode | Yes | Multi-Directional Air Control | Yes |
Noise Rating | Quiet (45 decibels or below) | Sleep Mode | Yes |
Minimum Outdoor Temperature (Fahrenheit) | -13 | Timer | Yes |
Heat Pump Included | Yes | Oscillation | Yes |
Pre-Charged Line Set | Yes | Remote Control Included | Yes |
Number of Speeds | 5 | Thermostat | No |
Voltage (Volts) | 115 | Lowe's Exclusive | No |
Overload Protection | Yes | Kit | Yes |
24 Hour Timer | No | Voice Controlled | Yes |
Auto Cool | Yes | ||
Compatibility | |||
|---|---|---|---|
Works with Apple HomeKit | No | Wi-Fi Compatibility | Yes |
Works with SmartThings | No | App Compatibility | App required |
Works with Amazon Alexa | Yes | Works with the Google Assistant | Yes |
Works with iOS | Yes | Bluetooth Compatibility | No |
Works with Android | Yes | Smart Compatible | Yes |
Warranty | |||
|---|---|---|---|
Warranty | 5-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | Safety Listing | cETLus safety listing | |
ENERGY STAR Certified | Yes | Seasonal Energy Efficiency Ratio (SEER2) | 23.6 |
AHRI Certified | Yes | Energy Efficiency Ratio (E.E.R.) | 14 |
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 40101700 | ||
Ratings may include incentivized customer reviews.
What Customers Are Saying
Customers overwhelmingly praise the mini split system for exceptional cooling performance and remarkably quiet operation, with most reporting rapid temperature improvements in various spaces. Many highlight straightforward DIY installation, noting they saved thousands avoiding professional fees, and appreciate how included instructions combined with online resources made setup manageable. A small number raise concerns about warranty limitations and support documentation clarity, though these issues are outweighed by widespread satisfaction. Overall, reviewers consistently recommend the system for reliable, efficient cooling and user-friendly installation.
Customer review summary generated by AI, including incentivized reviews.bad faith
Lowes lowered the price on the 36,000BTU Unit by $600 recently. Happened to notice and called to see if they would credit me. Said NO! even though I purchased it in August on the 11th, 2026. Today is 9.23.26.. Buyer beware!
From DIY 5th gen 1 zone 36000-BTU Ductless Mini Split Heat Pump Included 230-Volt
Cools good
Works great. Cools 900 square feet quickly. The instructions could be a bit better, because they cover several different models. Installation is pretty easy. I wish it had a true thermostat.
From DIY 5th gen 1 zone 36000-BTU Ductless Mini Split Heat Pump Included 230-Volt Verified Purchaser
9k BTU mini split
I installed this in an insulated shed where I now store wine barrels to age. Despite the installation documentation being somewhat out of date, and with slight variations from the youtube videos, this was a breeze to install. I installed the compressor on a wall bracket outside and leveling it wasn't much of a problem. The unit fired right up and both the compressor and the air handler at both dead quiet. Internet connectivity was a little tricky but they have a help line if needed. Amazing...
From DIY 5th gen Energy Star 1 zone 12000-BTU Ductless Mini Split Heat Pump Included 115-Volt
Thank you so much for the fantastic review, homevino!
Aging wine barrels in an insulated shed sounds like a fantastic project, and we are ... Read More
MrCool 24k Mini Split
unit works well. a good DIY project. this ain't is very quite. inside and outside.
From DIY 5th gen Energy Star 1 zone 24000-BTU Ductless Mini Split Heat Pump Included 230-Volt
Thank you for the 5-star review, MJA! We’re glad to hear your MRCOOL 24K Mini Split is working well and made for a great DIY project. It’s also wonde... Read More
Its ok, but way to expensive and wonky
The user manual is outdated and wrong, there are many very confusing steps that are not adequately outlined for clarity. It works well, but WAY TOO much cost when you can just get one without precharged lines and get a cheap vacuum pump at Harbor Freight. I will do that next time. Customer service is also mediocre at best and shipping was slow on another unit I cancelled. Saved over $1000 getting another brand!
From DIY 5th gen Energy Star 1 zone 12000-BTU Ductless Mini Split Heat Pump Included 115-Volt
We apologize sincerely for your experience. Would you mind privately messaging us with your name, phone number, email, and ticket number if you have ... Read More
Great unit for the price, cools my entire garage .
Had it for about two weeks now. It’s absolutely amazing and as easy to install as it’s says. Had an electrician to install my disconnect switch, but Installed the unit myself per the instructions and YouTube videos. Great buy!
From DIY 5th gen Energy Star 1 zone 18000-BTU Ductless Mini Split Heat Pump Included 230-Volt
Thank you so much for the fantastic 5-star review, Lee!
Keeping a garage cool during hot weather is no easy task, so we are thrilled to he... Read More
Attic Installation
I got this 12K BTU MrCool 5thGen DIY mini split for my finished attic. Installation was straightforward with no issues. I powered it on this afternoon and so far so good. It cooled the attic down to 78 in a couple of hours with the outside temperature over 90 degrees. I am really impressed on how quiet it is. Got the wifi up and running no problem. This is an important feature for me to be able to control AC while I’m away from home. Very pleased so far.
From DIY 5th gen Energy Star 1 zone 12000-BTU Ductless Mini Split Heat Pump Included 115-Volt
Thank you for this positive review, Mark! We appreciate that you chose MRCOOL® for your comfort. If you ever need assistance, please do not hesitate ... Read More
easy to install
this is my 3rd mr cool unit. the 5th gen is a great unit. it's easy to install. only issue is had was getting it online so I can use my phone. I got it now. so since I have 3 now do I get 3 hats ?
From DIY 5th gen Energy Star 1 zone 24000-BTU Ductless Mini Split Heat Pump Included 230-Volt
Thank you very much for this positive review! We really appreciate that you chose MRCOOL® for your comfort. If you ever need assistance with your uni... Read More
DIY install no problem!
This unit was extremely easy to install. The step by step directions were easy to follow, scan each steps QR code brings up a video. Once the unit was installed, it performed as expected. I highly recommend this unit. Only thing that a DIY person may have an issue with is getting power run and connected as it requires work in electrical panel.
Thank you so much for this positive review Mark! We really appreciate that you chose MRCOOL® for your comfort. If you ever need assistance, please do... Read More
The only thing worse than MRCOOL’s build quality is their customer service. Two months after installing the first unit, we still don’t have working air conditioning. What to know before you buy: Poor build & reliability – Units fail early, run loud, and the “DIY” design invites leaks and breakdowns. When things go wrong, don’t expect much help from warranty support. “DIY” is misleading – This isn’t plug-and-play. The instructions are disorganized, the tool list is long, and you’ll need real mech...
We apologize sincerely for your experience. Would you mind privately messaging us with your name, phone number, email, and ticket number if you have ... Read More
Hi Rodajo, thank you for your review! We’re glad to hear the system was easy to install and quickly cools your 900-square-foot space. We also appreci... Read More
