Lithonia Lighting Square EXRG Series Exit Sign Bundle












Items Included in this Collection


Item #3071992 |
Model #ECRG SQ M6
CUSTOMIZATION: The EXRG LED Exit Sign has an internal switch for red or green color selection
HOUSING: Features bright white thermoplastic housing; fully assembled single-face exit comes with an extra faceplate and red and green panel inserts
VOLTAGE: Dual-voltage 120/277, 60Hz
RATINGS / LISTINGS: UL Listed, meets all applicable requirements for UL 924, NFPA 101 (current Life Safety Code), NFPA 70 (NEC), FCC Title 47, Part 15, Subpart B and OSHA, Indoor damp location 50°F to 104°F (10°C to 40°C) listed
INSTALL / MOUNTING: Top, side and back mount options; Mounting pattern on canopy (top and side mount) and back plate (back mount) fits most standard size junction boxes
HOURS OF LIFE: The typical life of the LED lamp is 10 years
DESIGN FEATURE: Provides a minimum of 90 minutes illumination for the rated wattage upon loss of AC power to meet code required emergency lighting
BATTERY: 3.6V maintenance-free, rechargeable, nickel metal hydride
WARRANTY: 2-Year Limited Warranty
General | |||
|---|---|---|---|
Collection Name | Contractor Select ECRG | Power Source | Hardwired |
Color/Finish Family | White | Bulb Type | LED |
Exit Light Color | Red/Green | Voltage Type | 120/277 |
Type | Exit and emergency light | Light Fixture Material | Plastic |
Number of Bulbs Required | 0 | ||
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 19.09 | Width (Inches) | 4.33 |
Height (Inches) | 7.95 | ||
Features | |||
|---|---|---|---|
Lumens | 113 | Maximum Fixture Wattage | 3.5 |
Maximum Bulb Wattage | 3.5 | ||
Warranty | |||
|---|---|---|---|
Warranty | 2-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | No | Safety Listing | UL safety listing |
ENERGY STAR Certified | No | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 39111700 | ||
