Items Included in this Collection




Item #2509762 |
Model #CMXECXM301
2.5x longer air tool run time vs PORTER CABLE® 30 gallon 135 PSI compressors
30% Higher PSI than PORTER CABLE® 30 gallon 135 PSI compressors
29% Higher SCFM air delivery vs PORTER CABLE® 30 gallon 135 PSI compressors
23% Quieter than PORTER CABLE® 30 gallon 135 PSI compressors
Includes high flow regulator which provides 65% more usable air pressure delivered to the air tool
Oil lubed belt drive operation
High efficiency aluminum flywheel provides maximum cooling air flow over the pump
10 inch pneumatic wheels for maximum portability
Made in the USA with global materials
General | |||
|---|---|---|---|
Sub-Brand | N/A | Pump Type | Oil-lubricated |
Type | Electric | Number of Tools Included | 0 |
Motor Type | Induction | Phase | Single-phase |
Start Type | Electric start | Tank Style | Vertical |
Dimensions | |||
|---|---|---|---|
Fitting Size | 1/4-in | Weight (lbs.) | 167 |
Tank Capacity (Gallons) | 30 | Amperage | 15 |
Features | |||
|---|---|---|---|
Accessories Included | No | Maximum Pressure | 175 PSI |
Air Delivery SCFM @ 100PSI (CFM) | 0 | Noise Rating | Standard (71 decibels or above) |
Air Delivery SCFM @ 175PSI (CFM) | 0 | Portable | Yes |
Air Delivery SCFM @ 90PSI (CFM) | 6.2 | Rechargeable | No |
Cordless | No | Running Horsepower | 2 |
Decibel Rating (Decibels) | 76 | Stage | Single stage |
Engine Displacement (Cu. Centimeters) | 0 | Voltage (Volts) | 120 |
Warranty | |||
|---|---|---|---|
Warranty | 2-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | Safety Listing | CSA safety listing | |
CARB Compliant | Yes | ||
Compatibility | |||
|---|---|---|---|
For Use with Brad Nailing/Stapling | Yes | For Use with Cutting | No |
For Use with Air Brushing | Yes | For Use with Grinding | No |
For Use with Bolting | Yes | For Use with Spraying | Yes |
For Use with Finish Nailing | Yes | For Use with Sanding | No |
For Use with Framing Nailing | Yes | For Use with Surface Prep | No |
For Use with Roof Nailing | Yes | For Use with HVLP Painting | No |
For Use with Drilling | No | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 40151600 | ||
Ratings may include incentivized customer reviews.
What Customers Are Saying
The compressor has received mixed reviews, with some customers finding it to be a good value with satisfactory performance and quality, while others reporting various manufacturing and quality control issues. Positive feedback highlights the compressor's power, quiet operation, and compact design. However, a significant number of customers experienced problems such as missing oil, leaks, and issues with components like the pressure switch and tank. Despite these concerns, many were able to resolve the problems they encountered.
Customer review summary generated by AI, including incentivized reviews.Leaking Delivery
So I did my research and this compressor seemed to be a good match for me. I placed the order but when it arrived it was laying on it's side with the box full of oil. I rejected the delivery. I spoke to my Lowe's representative and they ordered me a new one with special instructions to ship vertical. Well the compressor box has oil all over it again so somewhere in shipping the box was laying down. Does no one at Craftsman's warehouse know to ship these things vertical or you damage the com...
Verified Pro
Compressor leaks air and Terrible Customer Support
I purchased this unit to replace a 20-year-old craftsman air compressor that I never had a problem with until recently. I stayed with the craftsman brand, even though I saw many reviews online from people saying that their units leaked air from day one. I decided to take a chance. My unit arrived with no damage to any packaging, and I proceeded to unpack the unit and run it through its break in process. After the break-in process and allowing the unit to fill with air, I could hear air leaking ...
Verified Purchaser
Well made
Compressor is half the size of my old one, end it works great.
Verified Purchaser
Took a chance....
I have been using a Craftsman pancake compressor for a few years now and have been casually looking at larger compressors for the last year or so. Almost pulled the trigger on the Kobalt Quiettech vertical compressor last Christmas but eventually decided against it. While walking my local Lowe's store on 4/29/23, I walked by a large box that had the famous yellow clearance sticker on it. I noticed the price said $279.99 (down from $699.99) but besides the yellow sticker, I noticed one of the sid...
Hi Raider,
We just wanted to take a moment to thank you for sharing such a thorough and positive review! We're so happy to hear you're ...

Great product
Highly recommend. Works fantastic! Rebuildable if you ever need to do that.
Verified Purchaser
runs great leaks live a seive
Purchased in February 2024. ran great till about a month ago. Pumps up and within 48 hours its completely drained. No leaks obvious. Did some research online and appears the Head Valve Plate Assembly w/ Gaskets #05AACE is defective.
Poor quality control
Not built by Craftsman Picked one up on clearance price, took it home and did the break in procedure only to find several air leaks! After retightening several fittings I found an unfinished weld on top of the tank! How does something like that get out of a manufacturer building…obviously no quality control. Lowe’s would not get another one at the clearance price so I’ll tear the fittings back off and repair it with my mig welder. Craftsman name seems to be just a sticker anymore. My last Craf...
Perfect garage compressor
This compressor is a major upgrade from my 25 year old Craftsman 5hp oilless 22gal unit, which was adequate for my needs, but i always wanted a bit more performance. The new unit has plenty of pressure (170 indicated when topped off) and has plenty of air volume for general residential shop work. It significantly outperforms the old one. All of my air tools (wiz wheels, angle grinder, etc) run much better now that i have a bit more volume. I can't speak for impact guns, as i don't really use my ...
Verified Purchaser
Ran great out of the box, holds pressure great.
Was in great shape right out of the box. Fired right up, ran the break-in no problems. Then pressed up tank in about 6 or 7 minutes to the full rated pressure. Came down to about 160psi after temperature normalization. Has held pressure perfectly ever since, kicks in & out at appropriate set points. No belt or pulley issues. No oil issues. No pressure loss when static and no leaks from any fittings when running or using. Only reason for 4 stars instead of 5 is that it's still pretty new ...
Verified Purchaser
Thanks for your review, we are glad to hear things are working well for you! We hope you'll continue to enjoy this air compressor. For any assist...

On/Off switching can be sketchy…..
Overall the compressor is built using decent products except for the “Lafoo” pressure switch. This switch malfunctioned since its inaugural use. When switching to the *Off* position, it would trigger back on/return to the *On* position all by itself. (It has a cheap/simple “on/off” lever snagging design) …Sooo,….I eliminated it and replaced it with a “Condor brand” *On/Off* pressure switch. The Condor switch (often found on similar models) looks so much better, switches on and off “easier”, and...
Verified Purchaser
Rich, thank you for your review, and we appreciate your input; we will share it with our quality team. If you need assistance in the future, feel fre...





We are very sorry to hear of these issues with this unit. We understand a team member has reached out to you to assist in this matter. If not resolve...
