Aluminum Sliding Patio Door Roller Assemblies

Prime-Line   Adjustable 1.25-in Nylon ball bearing Sliding Patio Door Roller Assembly

This mirror door roller is constructed from durable nylon and attached to a steel housing, featuring an adjustable bottom mount design with a rear screw for adjustable ride height. It is compatible with various mirror door manufacturers, making it a versatile option for different door systems. The roller has a 1-1/4-inch diameter concave shape and is designed with a stamped steel body and a nylon ball-bearing roller for added durability and smooth operation.

Prime-Line   Adjustable 1-in Plastic Tandem Sliding Patio Door Roller Assembly

The Prime-Line N 6848 pocket door roller assembly is compatible with a variety of bypass, bi-fold, and pocket closet doors, offering smooth and quiet operation for your sliding door needs. This roller assembly features a top-hung, center-mounted tricycle design with 1 inch flat rollers, ensuring seamless and long-lasting door movement. Built with a steel bracket and durable plastic rollers, this pocket door assembly provides reliable strength and quiet functionality for heavy-duty applications. The threaded rod easily installs into the bracket at the top of the door, making this closet door assembly quick and simple to set up with basic tools. Designed for 1-3/8 inch thick doors and tracks with a 1-1/8 inch inside width. For further dimensional information, please see the line drawing and compare it with your original item before purchasing.

Prime-Line   Adjustable 1.25-in Steel ball bearing Tandem Sliding Patio Door Roller Assembly

Upgrade your sliding doors with this back mount tandem roller assembly, designed for Andersen wood patio doors and compatible with many other wood door brands. Two 1-1/4 inch concave steel ball bearing rollers ensure smooth, quiet operation, while the stamped steel housing with side adjustment makes precise alignment simple. Top insert points and side locking tabs secure the assembly for long-lasting performance. Perfect for DIY homeowners or contractors, this durable roller assembly restores effortless sliding and improves door longevity. Installation is easy with a standard Phillips head screwdriver.

Prime-Line   Adjustable 1.5-in Aluminum Sliding Patio Door Roller Assembly

This is a plain back patio door roller assembly with a 1-1/2 in. concave or grooved steel ball bearing roller. It has a plain back housing that is 11/16 in. wide, 1-1/4 in. tall and 2-3/8 in. long. It is rear adjusting with a 1/4-20 threaded mounting hole on the back end and a #10-32 threaded optional use hole on the top. It is used by Daryl, Lenahan, Patio Magic and a variety of other manufacturers of sliding patio doors.

Prime-Line   Adjustable 1.25-in Steel ball bearing Tandem Sliding Patio Door Roller Assembly

This 1-1/4 inch plain back tandem roller assembly is designed for a variety of metal and vinyl sliding patio doors. It features two concave (or grooved) steel ball bearing rollers in an adjustable stamped steel housing for smooth, quiet operation. The housing measures 11/16 inch wide, 1-1/16 inch tall, and 3-1/8 inches long, and includes a 1/4-20 threaded mounting hole plus two narrow mounting slots that slide onto an opposite-shaped extrusion on the door frame. Perfect for DIY homeowners and contractors, this assembly restores reliable sliding performance to your patio doors.

Prime-Line   Adjustable 1.25-in Steel Sliding Patio Door Roller Assembly

This is a K-tab patio door roller assembly with a 1-1/4 inch concave or grooved steel ball bearing roller. The T-shaped tab (K-Tab) is simply slid up into a T-shaped receptacle in the bottom of the patio door. No screws are required. The housing is 5/8 inch wide and 1-3/16 inch tall with a flare and a 3/4 inch dimple width. Used by International and a variety of other sliding patio door manufacturers.

Prime-Line   1.5-in Nylon Sliding Patio Door Roller Assembly

This is a combination of a 1-1/2 inch diameter nylon concave or grooved ball bearing roller that is 5/16 inch thick with a 1/4 inch axle hole and a combination of 5 different axle choices. Depending on the application, you can choose to rivet the roller into place or use a roll pin, drive pin, binder post and screw or bolt and nut. Regardless of how you need to install the new roller into your existing roller housing, in most cases, one of the five choices will work.

Prime-Line   Adjustable 1.25-in Aluminum Sliding Patio Door Roller Assembly

This sliding glass door roller assembly is constructed from steel and features a height-adjustable housing. It is a "K" tab patio door roller assembly with a 1-1/4 in. concave or grooved nylon ball bearing roller. The "K" tab style back end is a T shaped tab that is simply slid up into a similar T shaped receptacle in the bottom of the patio door. No screws are required. The housing is 5/8 in. wide and 1-3/16 in. tall with a flare and 3/4 in. dimple width. The concaved (grooved) edge wheels installed in these roller assemblies are constructed of plastic and include steel ball bearings for smooth and long-lasting operation. The wheels are designed to glide on a single raised aluminum or steel track. This item includes only one roller assembly per package, but a total of 2 roller assemblies are required for each sliding door. These roller assemblies are used to repair patio sliding doors with missing, damaged or malfunctioning roller assemblies. Installation easy to install with a few simple tools. Refer to dimensional line drawing to match product specifications. This style roller is used on International and similar styled patio doors.

Prime-Line   Adjustable 1.125-in Aluminum Sliding Patio Door Roller Assembly

This is a K-tab patio door roller assembly with a 1-1/8 in. concave steel ball bearing roller. The T-shaped tab (K-tab) is simply slid up into a T-shaped receptacle in the bottom of the patio door. No screws are required for installation. The housing is 3/4 in. wide and 1-1/4 in. tall with a 7/8 in. dimple width. The dimples secure it within the door's bottom frame. Used by a variety of door manufacturers.

Prime-Line   2 -Pack Adjustable 0.875-in Steel ball bearing Sliding Patio Door Roller Assembly

Are you having trouble sliding your screen door open or closed? Have you checked your rollers/roller assemblies? Don’t replace the entire door. For a fraction of the cost of a new door, replace those worn-out rollers. This spring-loaded style sliding screen door roller is used doors made by Pacesetter. The steel housing has a steel inner housing with a 7/8 Inch steel ball bearing roller. The housing has a mounting tab with a hole for the installation screw to fit into. There is an adjustment screw at the end of the housing to adjust height. Order yours today and have your door slide like new.

Prime-Line   Adjustable 1.25-in Aluminum Sliding Patio Door Roller Assembly

This is a unique back patio door roller assembly with a 1-1/4 inch concave nylon ball bearing roller. The stamped steel housing is 11/16 inch wide and 1-3/8 inch tall. It is rear adjusting with a set of tabs or ears that insert into slots in the door's bottom rail. No mounting screws required. It is used by Premiere patio doors.

Prime-Line   Adjustable 1.5-in Aluminum Sliding Patio Door Roller Assembly

This is a K-tab patio door roller assembly with a 1-1/2 inch concave steel ball bearing roller. The T-shaped tab (K-tab) is simply slid up into a T shaped receptacle in the bottom of the patio door. No screws are required. The housing is 3/4 inch wide with a dimple width of 7/8 inch, 1-1/4 inch tall and 2-1/4 inch long. The dimples secure it within the door's bottom frame. Used by Marshall and a variety of other sliding door manufacturers.

Prime-Line   Adjustable 1.25-in Aluminum Sliding Patio Door Roller Assembly

This is an unique back diecast patio door roller assembly with a 1-1/4 inch concave steel ball bearing roller used on Crossly doors. It's unique diecast housing is 11/16 inch stepping down to 9/16 inch wide, 1-1/8 inch tall and 2-5/16 inch long with a flare width of 3/4 inch. The 9/16 inch wide rear design of the housing fits into the door rail held in place by a screw that engages the mounting hole in the back end. The adjustment screw is just above the mounting hole.

Prime-Line   Adjustable 1.25-in Aluminum Sliding Patio Door Roller Assembly

This is a plain back patio door roller assembly with a 1-1/4 inch concave or grooved steel ball bearing roller. It has a plain back housing that is 3/4 inch wide and 1-3/8 inch tall. It is rear adjusting with a 1/4-20 threaded mounting hole on the back end and an optional use #10-32 threaded hole on top. It is used by Air Control, Howmet, Krestmark and a variety of other manufacturers of patio doors.

Prime-Line   Adjustable 1.25-in Aluminum Sliding Patio Door Roller Assembly

This is a plain back patio door roller assembly with a 1-1/4 inch concave or grooved steel ball bearing roller. It has a plain back housing that is 9/16 inch wide with a 13/16 inch flare and 1-3/16 inch tall. It is rear adjusting with a threaded mounting hole on the back end. It is used by Nu-Air, Bennings, Scotty and a variety of other sliding patio door manufacturers.

Prime-Line   1.25-in Steel Sliding Patio Door Roller Assembly

These rollers are constructed of steel components and include a set of installation nuts and bolts for each. Each wheel has a concaved (center grooved) edge and features a steel inner race, steel ball bearings and a 1/4 inch inside diameter hole. The outside diameter of these rollers measures 1-1/4 inch and the width (or thickness) is 5/16 inch. These wheels are commonly used to repair damaged sliding patio door roller assemblies in both the glass and screen sliding door panels. These wheels are used by a variety of patio door manufacturers.

Prime-Line   Adjustable 1.125-in Steel ball bearing Sliding Patio Door Roller Assembly

This is a U-back patio door roller assembly with a 1-1/8 inch diameter concave, or grooved, steel ball bearing roller in a stamped steel U-back style housing. When installed, the U-back housing is drawn tightly into position against the side stile as the mounting screw or bolt is tightened. The housing is 1/2 inch wide, 1 inch tall with a rear adjusting screw. Most often used by Better-Bilt patio doors.

Prime-Line   Adjustable 1.25-in Aluminum Sliding Patio Door Roller Assembly

This is an F-tab patio door roller assembly with a 1-1/4 inch concave ball bearing roller that replaces the Old Style design. Used on Sun Valley, Fullview, Glasco and a variety of other sliding patio door manufacturers. When the corner screw passes through the "F" tab the assembly is captured by the side stile and bottom rail as the screw draws the two sides together. The housing is 9/16 inch wide and 1-9/32 inch tall, with a rear adjusting screw.

Prime-Line   Adjustable 1.5-in Steel ball bearing Sliding Patio Door Roller Assembly

This extra heavy-duty 1-1/2 inch stainless steel tandem roller assembly is designed for Kawneer sliding patio doors and other heavy-duty sliding door applications, including door walls often found in Hawaii. Featuring two concave (grooved) inline stainless steel ball bearing rollers in a diecast outer housing, it provides smooth, quiet operation and long-lasting durability. Rear adjustment allows precise alignment, while the housing includes two 1/4-20 mounting holes on the back and two on top for secure installation. Built to withstand severe weather conditions, this assembly is perfect for DIY homeowners or contractors seeking reliable performance. A Phillips head screwdriver is required for installation.

Prime-Line   Adjustable 1.5-in Aluminum Sliding Patio Door Roller Assembly

This sliding glass door roller assembly is constructed from steel and features a height-adjustable housing. The concaved (grooved) edge wheels installed in these roller assemblies are constructed of plastic and include steel ball bearings for smooth and long-lasting operation. The wheels are designed to glide on a single raised aluminum or steel track. This item includes only one roller assembly per package, but a total of 2 roller assemblies are required for each sliding door. These roller assemblies are used to repair patio sliding doors with missing, damaged or malfunctioning roller assemblies. Installation easy to install with a few simple tools. Refer to dimensional line drawing to match product specifications. This style roller is used on Highlight Doors and similar styled patio doors.
