Portable 15.6 in. Film Production Monitor The SWIT FM-16B monitor adopts a 15.6 inch 10 bit LCD panel with LED backlight 300nits brightness. The native resolution is Full HD 1920x1080 contrast 700:1 and viewing angle is Horizontal: 178 and deg;/Vertical: 178 and deg;Input/Output Interfaces FM-16B monitor supports: 2x 3G/HD/SD-SDI input 1x 3G/HD/SD-SDI loop output 1x HDMI 1.3 input 1x 3.5mm analog audio input 1x 3.5mm analog audio output 1x RS485 UMD input 1x RS485 UMD output 1x USB-A LUT/Firmware inputBuilt-In De-Log 3DLUTs FM-16B provides more than 20 De-log 3DLUTs to convert log mode to REC709 for all major cameras. Includes ARRI RED SONY Panasonic Canon JVC BMD FujiFilm GoPro DJI. And the user 3DLUT cube or calibrated 3DLUT cube can be uploaded by USB stick.Video Analysis Assistant Pattern Waveform/Vector scope/Histogram. FM-16B supports video analysis assistant patterns includes: Waveform Y/Pb/Pr/R/G/B Vector scope Histogram R/G/B/Y to convert the digital video quality info Luma Color Saturation etc to patterns and the patterns can be switched on/off individually select display position Up/Down/Left/Right size color and translucence.Embedded Audio Monitoring Up to 16-ch meters. The monitor can display 16-ch embedded audio meters. The display mode can be: 1. CH1-2 2. CH1-16 3. CH1-4 and CH5-8 4. CH1-4 and CH9-12 5. CH1-4 and CH13-16 6. CH5-8 and CH9-12 7. CH5-8 and CH13-16 8. CH9-12 and CH13-16Function Keys Assign 4 User Presets of Function Keys restore. There're 4 F-keys to assign different functions and you can make independent assignments and restore in 4 User Profiles. Lon
