MRCOOL DIY 5th gen Energy Star 1 zone 12000-BTU Ductless Mini Split Air Conditioner Heat Pump Included with 115-Volt
Item #6633406 |
Model #DIY-12-HP-WM-115D25O
View Lower Price In CartWhen we price an item lower than the manufacturer's suggestion, we can only show that price in cart.
View Lower Price In CartWhen we price an item lower than the manufacturer's suggestion, we can only show that price in cart.
Energy Star certified 23.5 SEER2, 10.2 HSPF
Easy DIY installation: pre-charged R-454B 25ft quick connect line doesn't require special tools, equipment, or training
Designed to efficiently heat and cool a single 350-550 Sq Ft room
SmartHVAC app: wifi control - compatible with amazon Alexa and Google assistant - you can control your DIY anywhere with your apple or android smart device and an Internet connection
Variable-speed DC inverter compressor technology cuts operating costs
Low ambient cooling: cooling down to 5F this feature makes the Mrcool DIY the ideal system for computer server rooms, greenhouses, and any other application that requires cooling all year
Gold fin condenser corrosion resistant - live on the coast, but don’t worry, our condenser is built to resist long-term corrosion
5-year parts warranty and 7-Year compressor
Follow me-feature, dehumidifying operation, auto mode, louver position memory, and sleep mode
General | |||
|---|---|---|---|
Color/Finish Family | White | Control Type | Dimmable LED |
Manufacturer Color/Finish | White | Filter Type | Nylon |
Series Name | DIY 5th gen Energy Star | Mounting Location | Wall |
Type | Quick connect (DIY) | Refrigerant Type | R-454B |
Application | Heating/Cooling | Number of Tons | 1 |
Dimensions | |||
|---|---|---|---|
Air Handler Depth (Inches) | 7.44 | Height (Inches) | 21.85 |
Air Handler Height (Inches) | 11.69 | Line-set Connection Size | 1/4-in x 3/8-in |
Air Handler Width (Inches) | 31.57 | Line-set Length | 25-ft |
Compressor Depth (Inches) | 11.93 | Maximum Coverage Area (Sq. Feet) | 550 |
Compressor Height (Inches) | 21.85 | Weight (lbs.) | 65.48 |
Compressor Width (Inches) | 30.12 | Width (Inches) | 30.12 |
Cord Length (Feet) | 25 | Zone Capacity | 1 zone |
Depth (Inches) | 11.93 | Amperage | 20 |
Features | |||
|---|---|---|---|
24 Hour Timer | No | Minimum Outdoor Temperature (Fahrenheit) | -13 |
Annual Fuel Utilization Efficiency % (Percentage) | 0 | Multi-Directional Air Control | Yes |
Auto Cool | Yes | Noise Rating | Quiet (45 decibels or below) |
Automatic Shut-Off | Yes | Number of Speeds | 5 |
Cooling BTU Rating (BTU) | 12000 | Oscillation | Yes |
Decibel Rating (Highest Setting) | 43 | Overload Protection | Yes |
Decibel Rating (Lowest Setting) | 18 | Pre-Charged Line Set | Yes |
Fan Only Option | Yes | Quiet Mode | Yes |
Full Load Amperage Requirement (Amps) | 20 | Remote Control Included | Yes |
Heat Pump Included | Yes | Sleep Mode | Yes |
Heating BTU Rating (BTU) | 12000 | Thermostat | No |
Hub Required | No | Timer | Yes |
Kit | Yes | Voice Controlled | Yes |
Low Voltage Compensation | Yes | Voltage (Volts) | 115 |
Lowe's Exclusive | No | ||
Compatibility | |||
|---|---|---|---|
App Compatibility | App required | Works with Android | Yes |
Bluetooth Compatibility | No | Works with Apple HomeKit | No |
Smart Compatible | Yes | Works with iOS | Yes |
Wi-Fi Compatibility | Yes | Works with SmartThings | No |
Works with Amazon Alexa | Yes | Works with the Google Assistant | Yes |
Warranty | |||
|---|---|---|---|
Warranty | 5-year limited | ||
Certifications | |||
|---|---|---|---|
AHRI Certified | Yes | Safety Listing | cETLus safety listing |
CA Residents: Prop 65 Warning(s) | Seasonal Energy Efficiency Ratio (SEER2) | 23.5 | |
Energy Efficiency Ratio (E.E.R.) | 12.5 | Heating Seasonal Performance Factor (HSPF) | 10.2 |
ENERGY STAR Certified | Yes | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 40101700 | ||
Check out the Best Selling Ductless Mini Splits on Lowes.com
Ratings may include incentivized customer reviews.
What Customers Are Saying
Customers overwhelmingly praise this mini split system for its straightforward DIY installation, quiet operation, and powerful cooling performance. Most highlight the clear step-by-step instructions and abundant online video guides that make setup manageable in just a few hours, though several note the condenser weight requires assistance. Reviewers consistently describe the unit as whisper quiet while delivering rapid temperature drops and maintaining desired settings even during door activity or appliance use. Many commend responsive customer service for troubleshooting support. A few report warranty limitations that exclude labor costs and mention receiving defective units or line set length constraints, but overall, most customers find the system highly effective and worthwhile.
Customer review summary generated by AI, including incentivized reviews.Unable to claim state rebate because of Lowes rece
I am unable to claim the rebate from he NH Dept of Energy because the receipt from Lowes gives a model number different from that on the condenser and air handler. The receipt gives one model number for both instead of listing the Mr. Cool model numbers for each component.
From DIY 5th gen Energy Star 1 zone 18000-BTU Ductless Mini Split Air Conditioner Heat Pump Included with 230-Volt Verified PurchaserVerified Pro
Great product
This product is amazing, it has so much cooling power we are absolutely thrilled with it .
From DIY 5th gen Energy Star 1 zone 24000-BTU Ductless Mini Split Air Conditioner Heat Pump Included with 230-Volt Verified Purchaser
Thank you so much for this positive review! We really appreciate that you chose MRCOOL® for your comfort. If you ever need assistance, please do not ...
Great solution for our HVAC needs
The units were easy to install, connect and get running in a short period of time. The system works great and will definitely keep our above-the-garage craft room comfortable all year round!
Verified Purchaser
MrCool = coolest and the ‘New Hotness’ all in one!
The installation was very straightforward and went smoothly. It’s both heats and cools efficiently, so much so we watched the electric meter to see if it registered a jump in power usage and it was almost unnoticeable. The unit also seems well built and well designed. I HIGHLY recommend the MrCool DIY units to anyone with moderate technical know-how. They are worth every penny vs the cheap units you have to pay a certified technician more than the price difference to install.
Verified Purchaser
Thank you so much for this positive review! We really appreciate that you chose MRCOOL® for your comfort. If you ever need assistance, please do not ...
Easy installation,works well
Easy setup,works well
From DIY 5th gen Energy Star 1 zone 24000-BTU Ductless Mini Split Air Conditioner Heat Pump Included with 230-Volt Verified Purchaser
Thank you so much for this positive review! We really appreciate that you chose MRCOOL® for your comfort. If you ever need assistance, please do not ...
Give air handler location some thought
Install simplicity
From DIY 5th gen Energy Star 1 zone 18000-BTU Ductless Mini Split Air Conditioner Heat Pump Included with 230-Volt Verified Purchaser
Thank you so much for this positive review Barkley! We really appreciate that you chose MRCOOL® for your comfort. If you ever need assistance, please...
Have a hole saw
Very easy to install
From DIY 5th gen 1 zone 36000-BTU Ductless Mini Split Air Conditioner Heat Pump Included with 230-Volt Verified Purchaser
Thank you so much for this positive review! We really appreciate that you chose MRCOOL® for your comfort. If you ever need assistance, please do not ...
Powerful Unit
Ease of installation
From DIY 5th gen Energy Star 1 zone 24000-BTU Ductless Mini Split Air Conditioner Heat Pump Included with 230-Volt Verified Purchaser
Thank you so much for this positive review! We really appreciate that you chose MRCOOL® for your comfort. If you ever need assistance, please do not ...
Get a friend to help install. Compressor is heavy.
Ease of install
From DIY 5th gen 1 zone 36000-BTU Ductless Mini Split Air Conditioner Heat Pump Included with 230-Volt Verified Purchaser
Thank you so much for this positive review! We really appreciate that you chose MRCOOL® for your comfort. If you ever need assistance, please do not ...
