Kobalt 12 inch Sliding Miter Saw 12-in 15-Amp Dual Bevel Sliding Compound Corded Miter Saw with Laser Guide
Item #1413795 |
Model #SM3017LW
This item is no longer sold on Lowes.com
Maximum crosscut up to 2 in x 16 in (nominal) at 90 degrees with innovative two position fence design, 2 in x 10 in at 45
Miter cuts up to 55 degrees left and 60 degrees right with 10 positive stops at most used angles
Two aluminum extension supports on both sides of table for added stability of workpiece
Front handle cam design for quick, accurate miter lock and Detent override
Tool-less adjustable upfront mounted laser guide system projects accurate pre-cutting line for precise alignment
Powerful 15.0 amp ball bearing motor, delivers 4,200 RPM for molding and framing cuts
Tall, 5-1/4 in high sliding fences support nested crown molding up to 7-5/32 in and baseboard up to 5 in against the fence
Bevel cutting up to 48 degrees left and right, positive stops at 0,33.9,45 and 48 degrees
Dual slide rail system with linear bearings allow for smooth and accurate operation
General | |||
|---|---|---|---|
Laser Color | Red | Series Name | 12 inch Sliding Miter Saw |
Dimensions | |||
|---|---|---|---|
Arbor Diameter | 5/8-in and 1-in | Length (Inches) | 27 |
Bevel Capacity (Degrees) | 48 | Maximum Fence Height (Inches) | 5.25 |
Cord Length (Feet) | 6 | Saw Blade Diameter | 12-in |
Depth of Cut at 45 Degrees (Inches) | 3.5 | Tool Weight (lbs.) | 52.2 |
Depth of Cut at 90 Degrees (Inches) | 3.5 | Width (Inches) | 30 |
Height (Inches) | 26.75 | Amperage (Amps) | 15 |
Features | |||
|---|---|---|---|
Bevel | Dual | Maximum Miter Cut - Right (Degrees) | 60 |
Bevel Lock Style | Clamp | Maximum Speed (RPM) | 4200 |
Blade Included | Yes | Miter Stop | Yes |
Charger Included | No | Number of Teeth | 40 |
Compound | Yes | Power Rating (HP) | 0 |
Cordless | No | Quick Release Vise | No |
Dust Handling | Port | Slide | Yes |
Electric Brake | Yes | Sliding Fence | Yes |
Folding | No | Spindle Lock | Yes |
Laser Guide | Yes | Worm Drive | No |
Maximum Miter Cut - Left (Degrees) | 55 | ||
Warranty | |||
|---|---|---|---|
Warranty | 3-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | Safety Listing | UL safety listing | |
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 27112700 | ||
Check out the Best Selling Miter Saws on Lowes.com
Ratings may include incentivized customer reviews.
What Customers Are Saying
The miter saw offers a range of features and functionality at a reasonable price point. Many users reported the saw was able to make clean cuts, especially on smaller pieces. However, a significant number of customers experienced quality control issues, such as the saw not cutting straight, the laser guide being ineffective, and the fence not properly aligned. Careful inspection and adjustment may be required to achieve accurate, consistent cuts with this model.
Customer review summary generated by AI, including incentivized reviews.Getting it Square is almost impossible!!!!
I have an older version of this and I believe they have changed it but there is no easy way to square the blade up. the only way to do it is to move the fence. The newer ones have screws you can loosen and move where the base locks in. It sucks I spent this money for them to change it after I bought it. I'm to the point I'm about to go to a different brand if i have to spend more money to be able to easily adjust the thing.
Verified Purchaser
Don't buy
Laser barley works, you can't see it at all
Verified Purchaser
It's a tad cumbersome to carry around
Picked it up on a clearance thing well worth the money
Verified Purchaser
Saw
Great 👍😃
Verified Purchaser
Happy
This saw was on sale along with DeWalt, the savings on this saw was enough for me to buy this saw. I fell this saw was a good buy, I'm happy with this saw so far.
Verified Purchaser
Great saw
The saw is super easy to use, arrived in excellent condition.
Verified Purchaser
saw
had to return damaged one from shipping but i bought the same one from the store. works incredible so far
Verified Purchaser
No More Kobalt
Bought 1, power switch and trigger were messed up. Occasionally it worked but when it did, when I stopped it, it didn't start again. Then if I put the power switch in the off position the saw would work. Returned the saw and got another identical one. It had the same switch, trigger problem. I'm writing off Kobalt power tools altogether.
I got mine for $244 at Lowes
great quality with great price. I am using it wit a diamond metal blade now with no problems
