DreamLine Prism Plus 2 -Piece 40-in W x 40-in L x 75-in H Neo-angle Corner shower kit (Corner Drain) Base and Door Dark bronze
Item #1070531 |
Model #DL-6062-22-06
Check Fee in Cart.
Kit-includes: Prism Plus Shower Enclosure and SlimLine Base; Kit Size: 40-in x 40-in x 74-3/4-in; Walk-In Opening: 23-1/8-in
Prism Plus Enclosure: Premium 3/8-in (10mm) thick certified tempered glass; DreamLine ClearMax water and stain resistant glass coating
Solid brass glass-to-glass self-closing hinges; L-Bar support brackets for stability
Side panels are attached to wall by 1-in stainless steel U-channels; U-channels allow 1/4-in adjustment per side for out-of-plumb (uneven walls)
SlimLine Shower Base: Low profile threshold design for easy entry and exit; Integrated tile flange for water leak prevention; cUPC certified
Glossy acrylic finish is scratch, slip, and stain resistant for safe showering; Reinforced with fiberglass for durability
Direct to stud installation; Professional installation recommended; Drilling into the threshold is required for installation of enclosure
Door Hardware Finish: Oil Rubbed Bronze; Base Color: Biscuit; Drain Location: Corner
Limited Lifetime Manufacturer Warranty (Oil Rubbed Bronze and Satin Black finishes limited to 1 (one) year warranty)
General | |||
|---|---|---|---|
Collection Name | Prism Plus | Items Required for Standard Installation | Tape Measure, Level, Silicone/caulk gun, Drill bits, Carpenter's square, Hex head driver bits, Metal file, Power drill, Professional grade glass suction cup, Safety glasses, Soft head hammer |
Color/Finish Family | Bronze | Wall Design/Pattern | No |
Hardware Finish | Dark bronze | Number of Towel Bars | 0 |
Manufacturer Color/Finish | Biscuit | Drain Location | Corner |
Manufacturer Door Finish | Oil Rubbed Bronze | Threshold Profile | Low threshold |
Series Name | Prism Plus | Number of Thresholds | Double |
Type | Corner shower kit | Floor Material | Acrylic |
Material | Tempered glass; Aluminum; Acrylic | Glass Style | Clear |
Shape | Neo-angle | Door Material | Tempered glass |
Package Contents | Prism Plus Shower Enclosure and SlimLine Base, hardware, door | Number of Seats | 0 |
Installation Type | Direct to Stud | Wall Material | Walls not included |
Number of Shelves | 0 | Door Position | Reversible |
Total Number of Pieces | 2 | Glass Pattern Name | Clear glass |
Frame Type | Frameless | Seat Location | Left or Right |
Door Type | Hinged | Shower Door Type | Frameless |
Dimensions | |||
|---|---|---|---|
Actual Assembled Height (Inches) | 74.75 | Common Assembled Length (Inches) | 40 |
Actual Assembled Length (Inches) | 40 | Common Assembled Width (Inches) | 40 |
Actual Assembled Width (Inches) | 40 | Common Height (Inches) | 75 |
Actual Door Opening Height (Inches) | 72 | Common Length (Inches) | 40 |
Actual Door Opening Width (Inches) | 23.125 | Common Measurement (W x L) Inches | 40 x 40 |
Actual Height (Inches) | 74.75 | Common Width (Inches) | 40 |
Actual Length (Inches) | 40 | Drain Diameter (Inches) | 3.375 |
Actual Shower Floor Height (Inches) | 2.75 | Glass Thickness | 3/8-in |
Actual Shower Floor Length (Inches) | 40 | Opening Size (Inches) | 40 |
Actual Shower Floor Width (Inches) | 40 | Product Weight (lbs.) | 219.36 |
Actual Width (Inches) | 40 | Threshold Height (Inches) | 1.75 |
Common Assembled Height (Inches) | 75 | Wall Height (Inches) | 0 |
Features | |||
|---|---|---|---|
Base Included | Yes | Integrated Seat | No |
Components Included | Base/door | Interlocking | No |
Corner | Yes | Lowe's Exclusive | No |
Door Included | Yes | Privacy | No |
Drain Included | No | Shaving Ledge/Foot Rest | No |
Faucet Included | No | Shower Head Included | No |
Folding Seat | No | Steam Feature | No |
Hardware Included | No | Wall Included | No |
Compatibility | |||
|---|---|---|---|
Compatible Drain | Drain Location: Corner; Drain not included | ||
Warranty | |||
|---|---|---|---|
Warranty | 1-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | No | ADA Compliant | No |
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 30181500 | ||
Check out the Best Selling Shower Stalls & Enclosures on Lowes.com
Ratings may include incentivized customer reviews.
What Customers Are Saying
Customers are sharply divided on this shower door. Many praise the sleek, frameless design and premium glass quality that enhances bathroom aesthetics and resists streaking. However, nearly as many report severe installation challenges, persistent leaks around hinges and seals, and hinges that cannot support the door's weight, causing sagging and gaps. Even when installed correctly, water floods the bathroom floor. While satisfied customers highlight the luxurious appearance and would repurchase if sealing issues were resolved, frustrated users find the product impractical for daily use despite its visual appeal.
Customer review summary generated by AI, including incentivized reviews.I regret purchasing this shower kit. The base is just fine. The door and walls not so much. Even with professional installation by an experienced installer, it proved to be extremely difficult to get the door and walls to line up. In fact, it proved to be too difficult. It demands perfection which is hard to do even by professionals. However, even if that is possible, the plastic and vinyl trim pieces have to be cut and notched to fit and really makes the whole thing look cheap. The instructions...
From Prism Plus 2 -Piece 42-in W x 42-in L x 75-in H Neo-angle Corner shower kit (Corner Drain) Base and Door Brushed nickel Hardware Included Verified Pro
incompetent workers
The first time they delivered the wrong item. After two weeks when that one sat in my livingroom, they delivered the right one, but the glass was damaged. Not a surprise considering the condition of the box. So now another two weeks wait. Maybe they will get it right eventually....
We’re very sorry to hear about the frustrating delivery experience you’ve had with Lowe’s. We understand how inconvenient it is to deal with incorrec...
Shower door
Nice quality happy with Door.
From Prism Plus Chrome 36-in W x 72.0-in H Frameless Clear Glass Neo Angle Hinged Shower door
Thank you for your feedback and for choosing DreamLine!
Beautiful enclosure, easy to install
Easy to install
From Prism Plus Chrome 36-in W x 72.0-in H Frameless Clear Glass Neo Angle Hinged Shower door Verified Purchaser
Thank you for your feedback and for choosing DreamLine!
These doors look amazing! They are high quality A+
From Prism Plus Matte Black 36-in W x 72.0-in H Frameless Clear Glass Neo Angle Hinged Shower door Verified Purchaser
Pick up at Lowes
My contractor had to wait for over an hour for employees to find my order. He had the receipt in his hand and I had received messages the order was ready. Despite ordering curbside pick up - he had so sit and wait while myriad Lowes staff first told him the order hadn't been received and then unable to find it. over an hour later - he had the equipment. Such an expensive waist of his time and am sure will be passed on to me. Quite frustrating!!
From Prism Plus 2 -Piece 38-in W x 38-in L x 75-in H Neo-angle Corner shower kit (Corner Drain) Base and Door Brushed nickel Hardware Included Verified Purchaser
We are sorry to hear about your negative experience with picking up your order. Unfortunately, DreamLine does not have any control over the policies ...
Like a dream
The product looks great and is well made.
From Prism Plus Oil Rubbed Bronze 36-in W x 72.0-in H Frameless Clear Glass Neo Angle Hinged Shower door Verified Purchaser
Thank you for your feedback and for choosing DreamLine!
Thick and heavy glass!
Love the thick glass. The only draw back is that the upper glass supports/adjusters are made for a complete wall (corner). I extended my shower area by a foot in one direction ,so one support/adjuster is on to a short area of 5"
From Prism Plus Oil Rubbed Bronze 38-in W x 72.0-in H Frameless Clear Glass Neo Angle Hinged Shower door Verified Purchaser
Thank you for your feedback and for choosing DreamLine!
Nice looking door, but leaks! Don't buy it!
Retro fit replacing an old framed door on a brand newly install base (tiled wall). Same problem as most others posted on this door, it leaks! Installed by a professional contractor with 25-years experience. His comments at the time of installation was there are very tight tolerances to adjust the shower door and hinges to achieve an even closure (big gap at the bottom of the door where it meets the fixed panel). Leaks terribly just below the bottom hinge and all along the bottom edge as the ...
From Prism Plus Brushed Nickel 34-in W x 72.0-in H Frameless Clear Glass Neo Angle Hinged Shower door
We are sorry to hear that you are not completely satisfied with your DreamLine Prism Plus. From what you describe, something may not be installed cor...
