Cobalt Digital CB-BBG-OE-MK2ST 3G-HD-SD-SDI-ASI-MADI Fiber Optic Transport Receiver with ST Connectors

The new Mark-II Blue Box BBG-OE-MK2 ( Fiber-To-Coax) throw-down converter unit is a new part of the Blue Box Group of compact, rugged, and portable converter boxes. Super-easy to use, BBG-OE-MK2 supports SMPTE 424M, 292M, and 259M as well as ASI and MADI audio. Auto-mode EQ/reclocking automatically sets to the signal type being received while allowing unrecognized formats to be safely passed without reclocking ( auto-reclock can also be manually disabled). Its wide operating range ( from 5Mbps to 3Gbps) flexibly supports most professional digital serial communications. Fully error-free pathological pattern operation is fully compatible with other professional fiber video interfaces. An SFP-based OE converter provides state-of-the-art fiber performance, power consumption, and compactness. BBG-OE-MK2 receives its operating power via a USB connection or using an AC adapter connection ( both included). These power sources can be simultaneously used to provide redundant power sourcing. Features. Full support of 5Mbps thru 3Gbps transport conversions, with seamless auto-mode EQ/reclocking. No switches to set for different payloads. Compatible with SMPTE 424M, 292M, 259M, 310M, M2S, DVB-ASI, and MADI audio. Input lock status indicator. Optical Rx power meter field allows optical Rx confidence assessment. Error-free pathological support. Full compatibility with other BlueBox Coax/Fiber units and Cobalt 9400-series openGear frame-installed fiber cards. SFP-based OE converter provides state-of-the-art fiber performance, power consumption, and compactness. Dual buffered/reclocked coax BNC outputs Specifications. Wavelength: 1260 to 1620 nm. Weight: 1 lbs
