A.O. Smith Signature 500 50-Gallon Tall 6-year Warranty 42000-BTU Power Vent Natural Gas Water Heater
Item #839899 |
Model #G6-UPVT5042NV
Delivers the ideal amount of hot water for households with 5+ people when sized appropriately
Features an environmentally-friendly 42,000 BTU Ultra Low Nox gas burner that delivers 71 gallons in the first hour
Electronic gas valve provides precise temperature control for optimum hot water delivery
This item is no longer sold on Lowes.com
Delivers the ideal amount of hot water for households with 5+ people when sized appropriately
Features an environmentally-friendly 42,000 BTU Ultra Low Nox gas burner that delivers 71 gallons in the first hour
Electronic gas valve provides precise temperature control for optimum hot water delivery
Self-diagnostic electronic gas control incorporates an LED status indicator that monitors and reports on the system's operational status
Built-in safety system protects against fires from accidental vapor ignitions
Tall, slim 65.625-in H x 19-in diameter profile installs easily in narrow spaces
Flexible power vent installation through the wall or roof up to 120 feet
High-altitude certified from 0 ft to 7,700 ft
Provides peace of mind with a 6-year limited tank and parts guarantee and a 1-year limited labor warranty
General | |||
|---|---|---|---|
Series Name | Signature 500 | Type | Tank |
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 22 | Rated Storage Capacity | 48-Gallon |
Diameter (Inches) | 22 | Vent Diameter(s) | 3-in |
Family Size | 5 | Water Connection Size | 3/4-in |
Height (Inches) | 65.625 | Weight (lbs.) | 183 |
Insulation Thickness (Inches) | 2 | Width (Inches) | 22 |
Nominal Capacity (Gallons) | 50 | ||
Features | |||
|---|---|---|---|
Annual Fuel Utilization Efficiency % (Percentage) | 0 | Pilot Light Window | Yes |
BTU Rating | 42000 | Pilot Reset Button | Yes |
Emission Rating | Ultra Low NOx | Point of Use | No |
Foam Insulation | Yes | Power Source | Gas |
For Use with Mobile Homes | No | Super High Efficiency | No |
For Use with RVs | No | Temperature and Pressure Relief Valve | Yes |
Fuel Type | Natural gas | Uniform Energy Factor | 0.65 |
GPH Recovery at 90 Degrees F (Gallons) | 43 | Use Location | Indoor |
Grade | Residential | Vent Type | PVC/ABS/CPVC |
Grid Capable | No | Venting Type | Power |
High Altitude Model | Yes | Water Connection Location | Top |
Ignition Type | Hot surface | Water Heater Style | Tall |
Compatibility | |||
|---|---|---|---|
Bluetooth Compatibility | No | Works with Apple HomeKit | No |
Smart Compatible | No | Works with iOS | No |
Wi-Fi Compatibility | No | Works with SmartThings | No |
Works with Amazon Alexa | No | Works with the Google Assistant | No |
Works with Android | No | ||
Warranty | |||
|---|---|---|---|
Warranty | 6-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | Safety Listing | CSA safety listing | |
ENERGY STAR Certified | No | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 40101800 | ||
Ratings may include incentivized customer reviews.
Control function are easy to use
We had good luck with AO Smith water heater. The old one was replaced after 12 years and still working, but placed it for preventative measures.
From aosmith.com
Nice upgrade.
So far so good. It was a bit tricky getting all set up. Lots of codes to deal with. Not used to that. But I will say it good the temperature very well for a very long time. Like a day or two with out using any gas to reheat.
From aosmith.com
AO Smith Power Vent Water Heater
We purchased a power vent water heater since it is located in the garage with no chimney access. This unit was installed smoothly. Used 2" ABS piping with two 90 degree joints to vent the exhaust out via to a side-wall of the garage. The noise is a fairly low volume hum that can't be heard inside our home unless an adjacent window is open.
From aosmith.com
Design and features
I am replacing an older AO Smith W/H same type 14 years old
From aosmith.com
Efficient
I purchased the tank in early spring and it was installed by Lowes in mid June. This tank is an upgrade from electric to gas in our newly remodeled home. The tank has performed quite well and is very efficient so far. It recovers quickly & easily supplies all the hot water we need. The thing that impressed me most is how quiet this power vent tank is compared to the power vent tank in my previous home. This tank can barely be heard when your near it & the other tank could be heard anywhere in th...
From aosmith.com
Fine water heater
I've had this water heater for over a year without issue. The only nit I've noticed so far is the plastic drain valve, which ideally would be switched out for a brass one.
