A.O. Smith Signature 900 50-Gallon Tall 10-year Limited Warranty 4500-Watt Double Element Electric Water Heater with Hybrid Heat Pump
Item #816193 |
Model #HP10-50H45DV
Ideal hot water delivery for households with 3-4 people when sized appropriately
With annual energy costs as low as 113 dollars, giving you an estimated 306 dollars or more in annual savings, heating water with a heat pump is 3x more efficient than a standard electric water heater
Saves an average 3,000 dollars over 10 years in standard projected operating expenses versus a comparable standard electric water heaters
Tall and slim 63-in H x 22-in diameter profile is designed for easier installation
Easy to use electronic interface allows you to change the temperature and select from 4 operating modes - efficiency, hybrid, electric, and vacation - for maximum efficiency and performance
Washable filter is also easy to access and clean, so you can prevent dust and grime from invading the heating system
10-Year limited tank and parts, 1-Year limited labor warranty gives you peace of mind
Two back-up 4,500-watt copper heating elements provide a first hour delivery of 66 gallons
General | |||
|---|---|---|---|
Series Name | Signature 900 | Grade | Residential |
Type | Tank | Use Location | Indoor |
Power Source | Electric | ||
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 22 | Nominal Capacity (Gallons) | 50 |
Diameter (Inches) | 22 | Rated Storage Capacity | 46-Gallon |
Family Size | 4 | Water Connection Size | 3/4-in |
Height (Inches) | 63 | Weight (lbs.) | 196 |
Insulation Thickness (Inches) | 2 | Width (Inches) | 22 |
Features | |||
|---|---|---|---|
Annual Fuel Utilization Efficiency % (Percentage) | 0 | Super High Efficiency | Yes |
Foam Insulation | Yes | Temperature and Pressure Relief Valve | Yes |
GPH Recovery at 90 Degrees F (Gallons) | 20.7 | Uniform Energy Factor | 3.42 |
Grid Capable | No | Voltage (Volts) | 240 |
Hybrid Heat Pump Technology | Yes | Water Connection Location | Side |
Point of Use | No | Water Heater Style | Tall |
Compatibility | |||
|---|---|---|---|
Bluetooth Compatibility | No | Works with iOS | Yes |
Smart Compatible | Yes | Works with SmartThings | No |
Wi-Fi Compatibility | No | Works with the Google Assistant | No |
Works with Amazon Alexa | No | For Use with Mobile Homes | No |
Works with Android | Yes | For Use with RVs | No |
Works with Apple HomeKit | No | ||
Warranty | |||
|---|---|---|---|
Warranty | 10-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | Safety Listing | UL safety listing | |
ENERGY STAR Certified | No | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 40101800 | ||
Check out the Best Selling Water Heaters on Lowes.com
Ratings may include incentivized customer reviews.
What Customers Are Saying
The hybrid water heater offers mixed performance. Some users report efficient hot water delivery and cost savings, but many experience frequent compressor/heat pump failures, unreliable hybrid mode, and noisy operation. Installation can also be challenging. While the product provides benefits for some, the high failure rate and poor customer support from the manufacturer appear to outweigh the advantages for many reviewers.
Customer review summary generated by AI, including incentivized reviews.Compressor failures common
Like many other reviewers, my compressor failed pretty quickly and the unit flashed ECC error. Tech support recommended restarting it and I did, and it did it again and I called again. Then they sent me two mother boards to see if that would fix it. So I did and it didn't, then they suggested I use a digital thermometer to measure the difference between the input and output air temperature, and I did. While going on with my life and restarting the heater a few times a week, this ultimately w...
AO Smith American made NIghtmare
Do not buy! Less then 3 years from install and the tank has failed. THE WARRANTY PROCESS IS THIS. 1:Call 2: Send in pictures 3: Get RMA number 4: YOU UNINSTALL IT AND RETURN IN TO LOWES (ON YOUR DIME) Lowe's will be difficult like always 4) They will give you a gift card 5) YOU HAVE TO REINSTALL IT
Recurring ECC120 Error – On My 3rd Unit in 5 Years
2020 purchased the **A.O. Smith Signature 900 50-Gallon Hybrid Electric Water Heater** based on its energy efficiency and 10-year limited warranty. This 2nd unit in just under 5years and facing the same **ECC120 error code** once again 3rd unit** if replaced or Company trying not to replace do to many RETURNS. Look up BBB & CFPB Complaints. If I had known this model would fail roughly every 2 years, I never would have chosen it. The ECC120 error points to a failure in the heat pump system, w...
Verified Purchaser
We are sorry to hear of your experience. We want to ensure the issue is resolved.
Please send your phone number to talktous@aosmith.c...
Multiple Failures
I was pretty excited to realize the savings from the HP WH. Unfortunately, my first unit failed shortly after 1 year (compressor) and the replacement is now leaking. There clearly is a workmanship/quality issue with these units. I can see from the other reviews that I am not alone. Unfortunately, the Lowes service plan and AO Smith warranty don't seem to offer a refund so I can go back to an all electric unit or a different manufacturer's product.
Verified Purchaser
Good heater if you only have 6 months to live
I really was looking forward to the efficiency of a heat pump water heater. Unfortunately it only lasted 6 months. Warranty replaced it (another big hassle) and the 2nd one lasted 6 months. Beyond disappointing
Two 50 gallon heat pump water heaters failed
We had the heat pump portion of two of these water heaters fail within 30 months of purchase. There is a systematic problem
From aosmith.com
Signature 900 50-Gallon Tall 10 year limited warra
Failed after 1.5 yrs. 10-year limited warranty - I don't even know what that means. Manufacturer supposedly arranged a return back to store for me, so that means I'm having to uninstall this myself, take it back to Lowes by myself, get store credit. Which is better than nothing. However, I paid $1,300 bucks for this defunct thing, and its current price is $1,950. Which means I can't even buy one anymore. Avoid this product.
Verified Purchaser
Aosmith hybrid failures
I installed 19 50 gallon Aosmith hybrid hot water heaters in Holliston Ma. 10 of them have failed within two years. This product has systemic failure. Aosmith has done everything they can to not support the homeowners and fighting a huge Missouri company is impractical. Using this product is a mistake.
From aosmith.com
Heat pump does not maintain temp
Do not buy. Nothing but problems. The hybrid mode can't maintain temp so u might as well get a standard one
From aosmith.com
So far it's been working 9mo. 6days
Received March 30,2023 move in house in April set it up and forget it. It's about time to clean filter.
Verified Purchaser
