A.O. Smith Signature 300 50-Gallon Tall 12-year Warranty 40000-BTU Natural Gas Water Heater
Item #816131 |
Model #G12-CADT5040NV
Delivers the ideal amount of hot water for households with 5+ people when sized appropriately
Fitted with an automatic flue damper that opens and closes automatically to increase efficiency and reduce heat loss in standby mode
Simple installation that uses standard 3-in or 4-in vent ducting and requires no power
Features an environmentally friendly 40,000 BTU low NOx gas burner that delivers 75 gallons in the first hour
Tank Guard® provides advanced tank protection that extends the life of your gas water heater
Tall, slim 61.25-in H x 22-in diameter profile enables easier installation in narrow spaces
High-altitude certified from 0 ft to 10,100 ft
Provides peace of mind with a 12-year limited tank and parts guarantee and a 1-year limited labor warranty
General | |||
|---|---|---|---|
Series Name | Signature 300 | Fuel Type | Natural gas |
Type | Tank | Ignition Type | Piezo |
Power Source | Gas | Venting Type | Atmospheric |
Grade | Residential | Vent Type | Type B double wall |
Use Location | Indoor | ||
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 22 | Rated Storage Capacity | 48-Gallon |
Diameter (Inches) | 22 | Vent Diameter(s) | 3-in; 4-in |
Family Size | 5 | Water Connection Size | 3/4-in |
Height (Inches) | 61.25 | Weight (lbs.) | 160 |
Insulation Thickness (Inches) | 2 | Width (Inches) | 22 |
Nominal Capacity (Gallons) | 50 | ||
Features | |||
|---|---|---|---|
Annual Fuel Utilization Efficiency % (Percentage) | 0 | Pilot Reset Button | Yes |
BTU Rating | 40000 | Point of Use | No |
Emission Rating | Low NOx | Scale Prevention | No |
Foam Insulation | Yes | Super High Efficiency | No |
GPH Recovery at 90 Degrees F (Gallons) | 40 | Temperature and Pressure Relief Valve | Yes |
Grid Capable | No | Uniform Energy Factor | 0.68 |
High Altitude Model | Yes | Water Connection Location | Top |
Pilot Light Window | Yes | Water Heater Style | Tall |
Compatibility | |||
|---|---|---|---|
Bluetooth Compatibility | No | Works with iOS | No |
Smart Compatible | No | Works with SmartThings | No |
Wi-Fi Compatibility | No | Works with the Google Assistant | No |
Works with Amazon Alexa | No | For Use with Mobile Homes | No |
Works with Android | No | For Use with RVs | No |
Works with Apple HomeKit | No | ||
Warranty | |||
|---|---|---|---|
Warranty | 12-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | AHRI Certified | Yes | |
ENERGY STAR Certified | No | AHRI Certification Number | 206350514 |
Safety Listing | UL safety listing | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 40101800 | ||
Check out the Best Selling Water Heaters on Lowes.com
Ratings may include incentivized customer reviews.
What Customers Are Saying
The water heater is praised for its efficient design, quick heating capabilities, and overall reliable performance. Customers are generally satisfied with its features and quality. Many found the installation process to be straightforward, though some noted minor issues. The product is seen as energy-efficient, potentially leading to cost savings. While a few customers reported minor problems, the consensus is that the water heater is a quality product that meets most customers' hot water needs.
Customer review summary generated by AI, including incentivized reviews.Four year old water heater cannot be fixed
The gas actuator on mine started to leak gas when it heats after four years. The linkage still functions, but there is gas leaking from within the body. Simple part replacement with a single retention screw and one supply line connection you'd think. Come to find out this part has been discontinued by the manufacturer so now I am supposed to return the whole hot water tank to Lowe's to replace it. I assume the design has changed or something, but returning a whole water heater over this simple p...
Just works!
Good size, adjustable temperature with pre-marked levels.
From aosmith.com
Great Price
I bought this product to replace a similar water heater that was 22 years old. So far so good. Produces hot water faster than the old unit. There were some "burn in" smells in my garage for the first week after installation. Some may have been from the soldering of the copper water pipes. Now I dont' smell the odors.
From aosmith.com
So far so good
Got hot water, nothing to complaint yet. Would recommend.
From aosmith.com
Nice and neat, supplies the heat!
Product has performed well, how often to drain and refill?
From aosmith.com
Great Feature
Excellent performannce, but pilot burner went off once.
From aosmith.com
Excellent water heater
I bought this water heater over a month ago and its doing a great job. Plenty of hot water for our family
From aosmith.com
Simple controls, easy installation.
Curbside pick up was easy. The associate who loaded it into my s. UV was courteous and efficient. The water heater is fine. Unlike the newer models, it has a mechanical gas valve: no electronics. I like this as there's less to go wrong. Plus since it doesn't plug into electricity, we'll have hot water even during an extended power outage.
Verified Purchaser
Gas leak
I bought this water in June 2022. After using it for 2 year, the control value starts having gas leak and I can smell it inside the house. Also, there is an issue with the heating. It overheated and tripped the sensor and turned off the pilot. The water heater is only 2-years old but has had multiple issues.
From aosmith.com
