A.O. Smith Signature 100 Series 6-Gallon Compact 6-year Limited Warranty Point Of Use Electric Water Heater
Item #816162 |
Model #E6-6C15SV
Delivers the ideal amount of hot water for specialized applications and small capacity needs
Features a single 1,500-watt copper heating element that provides a first hour delivery of 7 gallons at 90 degrees Fahrenheit
Low-profile 15.25-in high x 14.25-in diameter design allows for easy installation under counters or inside cabinets
Optional side or top connections are available
Provides superior tank protection and extends water heater life with premium heating elements, anode rod and fused ceramic tank shield
Reduces heat loss with non-CFC polyurethane foam insulation for maximum efficiency and energy savings
Features easy temperature control with adjustable thermostat you can set higher or lower for dishwashers and laundry machines
Factory-installed temperature and pressure relief valve and tamper-proof drain valve ensure safe operation
Provides peace of mind with a 6-year limited tank and parts guarantee and a 1-year limited labor warranty
General | |||
|---|---|---|---|
Series Name | Signature100 | Grade | Residential |
Type | Tank | Use Location | Indoor |
Power Source | Electric | ||
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 14.25 | Nominal Capacity (Gallons) | 6 |
Diameter (Inches) | 14.25 | Rated Storage Capacity | Not applicable |
Family Size | 1 | Water Connection Size | 3/4-in |
Height (Inches) | 15.5 | Weight (lbs.) | 35 |
Insulation Thickness (Inches) | 1.125 | Width (Inches) | 14.25 |
Features | |||
|---|---|---|---|
Annual Fuel Utilization Efficiency % (Percentage) | 0 | Scale Prevention | No |
Foam Insulation | Yes | Super High Efficiency | No |
GPH Recovery at 90 Degrees F (Gallons) | 7 | Temperature and Pressure Relief Valve | Yes |
Grid Capable | No | Uniform Energy Factor | 0.98 |
Hybrid Heat Pump Technology | No | Voltage (Volts) | 120 |
Installation Location | N/A (Portable) | Water Connection Location | Top |
Point of Use | Yes | Water Heater Style | Mini tank |
Compatibility | |||
|---|---|---|---|
Bluetooth Compatibility | No | Works with iOS | No |
Smart Compatible | No | Works with SmartThings | No |
Wi-Fi Compatibility | No | Works with the Google Assistant | No |
Works with Amazon Alexa | No | For Use with Mobile Homes | Yes |
Works with Android | No | For Use with RVs | No |
Works with Apple HomeKit | No | ||
Warranty | |||
|---|---|---|---|
Warranty | 6-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | AHRI Certified | No | |
ENERGY STAR Certified | No | AHRI Certification Number | 0 |
Safety Listing | CSA safety listing | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 40101800 | ||
Check out the Best Selling Water Heaters on Lowes.com
Ratings may include incentivized customer reviews.
What Customers Are Saying
This compact water heater is generally well-received for its small size and ability to quickly provide hot water, making it a suitable replacement for larger models, especially in limited spaces. However, some customers reported issues with missing connection fittings and problems with the water connections during installation, which caused difficulties. A few also received units that were damaged upon delivery. Overall, it offers good value as a small water heater, but users should be prepared for potential installation challenges.
Customer review summary generated by AI, including incentivized reviews.There’s a lot of time and money involved in getting the necessary connections, measurements and everything else needed for installation. Then when you get it installed it’s Leaking from the bottom. Extremely frustrating, and very disappointed in A O Smith quality.
Verified Purchaser
Compact fit
Fit perfect under the sink and worked well.
Verified Purchaser
quality?
plastic drain valve was broken before shipping.anode plug leaked no tape.
Verified Purchaser
We are sorry to hear of your experience. We want to ensure the issue is resolved.
Please send your phone number to [email protected]...
great, lots of hot water
actually had fun washing dishes with plenty of hot water.
From aosmith.com
6 gallon electric water heater
Easy installation, great quality
Verified Purchaser
Planned obsolescence
it lasts 6.5 years - this is the 3rd one in 13 years
Verified Purchaser
No nipples.
it shows nipples in the picture but just unboxed it on the job and there are no nipples to attach to. So make sure you pick up a set of nipples to thread into the tank. The box was in perfect shape so nobody stole them from it.
The compact does not come with the inlet and outlet connections.
Great Product
I bought this over a year ago and it has been more than adequate to provided hot water for showers, and washing at same time
