Toro TimeCutter MAX 54-in 23-HP V-twin Gas Zero-turn Riding Lawn Mower Parts & Accessories Bundle
Collection Items
When should I expect to get my items?
See availability by item


Items Included in this Collection



Item #5519964 |
Model #77504
Its heavy duty steel IronForged™ Deck doesn't flinch no matter what you throw its way
Get the pro-level power, durability, and precision to take on big acreage with thicker steel and lightning-fast blades
Premium 23HP, 726cc Kawasaki V-Twin engine gives you the power to Rule the Land
Any cut height, on the go - the deck lift pedal lets you save your deck without breaking a sweat for easy height-of-cut adjustment.
Take your throne - the 19 in handcrafted high-back gaming style seat delivers ridiculous comfort and insane back support.
Ultimate Traction - massive 20" Voodoo X508 drive tires feature wide aggressive tread that delivers ultimate traction.
Automotive Style Fuel Fill - fewer spills and less mess with automotive style fueling and a larger 5 gallon tank.
Shuts down sprayback - spray blocking fenders keep tire spray off your engine, and more importantly, you.
Stay hydrated, keep crushing - the built-in drink holder keeps your beverage handy so you can keep powering through.
General | |||
|---|---|---|---|
Blade Engagement Type (PTO) | Electric | Power Source | Gas |
Deck Type | Fabricated | Seat Type | High-back with lumbar support |
Drive Type | Rear wheel drive | Series Name | TimeCutter MAX |
Engine Type | V-twin | Start Type | Turn key start |
Number of Deck/Anti-Scalp Wheels | 3 | Transmission Type | Dual hydrostatic |
Oil Filter Type | Spin-on | Type | Zero-turn riding lawn mower |
Dimensions | |||
|---|---|---|---|
Cut Width (Inches) | 54 | Minimum Cutting Height (Inches) | 1.5 |
Engine Oil Capacity (oz.) | 80 | Overall Length (Inches) | 82 |
Front Wheel Size | 12-in | Overall Width with Deck (Inches) | 54 |
Fuel Capacity (Gallons) | 5 | Rear Wheel Size | 20-in |
Maximum Cutting Height (Inches) | 5 | Weight (lbs.) | 653 |
Features | |||
|---|---|---|---|
Ammeter | No | Engine Horsepower | 23 |
Bagger Capable | Yes | Engine Oil Included | Yes |
Bagger Included | No | Front Axle | Fabricated steel |
Charger Included | No | Grease Fittings | Yes |
Commercial/Residential | Residential | Headlight(s) | No |
Cruise Control | No | Lowe's Exclusive | Yes |
Cup Holder | Yes | Maximum Forward Speed (MPH) | 7 |
Deck Gauge | 10 | Maximum Reverse Speed (MPH) | 3 |
Discharge Location | Side | Mulching Capable | Yes (kit sold separately) |
Engine Brand | Kawasaki | Number of Blades | 3 |
Engine Displacement (Cu. Centimeters) | 726 | Operator-Controlled Mow-in-Reverse | Yes |
Compatibility | |||
|---|---|---|---|
Attachment Compatible | Front and rear | Recommended Yard Size | 3 to 5 acres |
Matching Bagger (Item #) | 5658629 | Replacement Belt OEM Part Number | 147-2910 |
Matching Mulch Kit (Item #) | 5657123 | Replacement Blade OEM Part Number | 115-2454-03 |
Recommended Terrain Type | Flat with obstacles | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 21101700 | ||
Ratings may include incentivized customer reviews.
What Customers Are Saying
The mower is generally well-received, with customers praising its performance, power, and ease of use. It efficiently cuts large lawns, reducing mowing time. Customers appreciate the comfortable ride, sturdy construction, and overall quality. However, some have experienced issues with the deck belt, hydraulic pumps, and lack of certain features. Despite occasional drawbacks, the consensus is that the mower is a reliable and high-performing zero-turn model that provides good value.
Customer review summary generated by AI, including incentivized reviews.Shipping Nightmare!
I purchased this product and scheduled shipping over a week later to ensure a date when I would be home, as the window is from 8 AM until 8 PM. The night before, I received a confirmation that the new 4 hour window was from 9 AM until 1 PM. After the mower didn't arrive, I reached out the Lowe's for them to inform me that the new window was between the time that I called and 8 PM (so I went from a narrowed 4 hour window to a new 7 hour window). By 7:30 at night, I still didn't receive a call fro...
Ordered online, delivery was awful!
Lowe's Home Improvement BLUF: Be prepared for major aggravation if you purchase big ticket items online from Lowe's. After researching mowers, I chose this model. I haven't even used it yet but the delivery was so bad I decided to post a review. I purchased this zero turn mower from Lowe's online on 4/13. It was originally scheduled for delivery on 4/22 so I took the day off because I was told an adult needed to be present to sign for it. It didn't show but the app showed a new delivery ...
Thank you for taking the time to share your valuable feedback, and we are sorry to learn of the delay you've experienced with your recent order f...

Great product, poor assembly by Lowe's or whoever.
I bought this Toro mower after my Yellow in color zero turn stopped running for the last time. This mower has been great. the only negative I have, I discovered it was missing parts after I had it for several months. I called Toro, who sent me the parts, but that shouldn't have happened.
Doesn't come with hour meter or arm rests.
I bought a Toro Timecutter back in 2012. It came with both an hour meter and arm rests. On this 2025 model, it comes with neither. I had to search the internet to find a set of arm rests. Then, I went on Youtube to see if I could install an hour meter. I was fortunate enough to find a video that showed how to do it. I found where the cut out is located and opened it up. The video also showed where there is a "pig tail" to plug the hour meter in to. I purchased an aftermarket meter and plugged it...
Verified Purchaser
Missed deliveries, cancelled orders, broken mowers
First mower was delivered to wrong address, after bouncing around multiple support lines for hours, no one could help me. The couldn't correct the address, cancelled the order, and lost me the financing special, never called back on my case. Re -ordered mower, they missed delivery window, after the window passed i got a call they wouldnt be coming, after waiting 4 hours all day, they couldnt even give me the courtesy to call me and let me know it wasn't even loaded, but they knew that. Mower w...
Verified Purchaser
James, we are sorry to hear about the issue. We suggest you contact Lowe's as a point of sale for any order and delivery-related issues. We also ...

Big
[This review was collected as part of a promotion.] I like the Toro Timecutter Black Max 54". It has replaced my old Toro Timecutter I bought in 2011. My old one had 1700 hours and still was running strong. The only problems I ever had with it was change out a solenoid and replace a deck belt. Not to bad for 14 years. I hope this new one will last as long as my old one. I put my trust in Toro Timecutters.
From Toro.com
Good, only if you dont care about cut quality.
I was looking to replace my 20 year old craftsman mower, and the choice was between this or a Bad Boy. I chose this Toro due to the Kawasaki engine and Lowe's better warranty. The chassis quality is great and sturdy, I feel like a king sitting on it, with its comfortable seat. Unfortunately, I am left disappointed when I turn around to see what I've mowed. I always mow at full throttle and dont even mow fast enough for the engine to lose RPMs. The blades are sharp and not upside down. Deck is cl...
Great and easy to use
[This review was collected as part of a promotion.] No issues, completely satisfied with the way it runs, drives, and the precision of the cut, overall great.cuts a few acres without hesitation.can't complain.
From Toro.com
New property, new mower!
[This review was collected as part of a promotion.] New mower, had a small issue, oil leak. The oil drain plug/valve was installed pinpointed 180’ from the correct spot. Took it in for serv, under warranty, got it replaced. No more leak. Other than that, the mower runs and operates great. No complaints.
From Toro.com
The first one had an electrical problem. Fred
I researched several brands of mower. Living in a rural area unwanted grass is a big deal. The Hustler Raptor I had was doing well, but an unfortunate accident sidelined it. For my purposes the TORO 54", 23 HP Kawasaki filled the bill. I ordered one at Lowe's. The cashier helped me effect the purchase, and I received the mower a couple of days later. The delivery staff made cursory adjustments and then left. I went through the instruction manual, checked oil, added 91 octane ethanol free gasol...
Verified Purchaser






















We are sorry to learn about your experience. We suggest you contact Lowe's, as they are the point of sale and may help you with your query. Addit...
