Graco X5 Electric Stationary Airless Paint Sprayer and Accessories
Collection Items
MULTIPLE_DATES_FOUNDWhen should I expect to get my items?
See availability by item
View Lower Price In CartWhen we price an item lower than the manufacturer's suggestion, we can only show that price in cart.
Item #295429 |
Model #262800
Sprays unthinned paint and a variety of other coatings
Adjustable spray speed to suit whatever your project demands
Great for indoor/outdoor projects like fences, decks or house
Just right for DIY Homeowners and Remodelers looking for more power and mobility when tackling larger projects
Ideal for projects up to 10 gallons in size, allowing you tackle multiple projects every year
Fully adjustable pressure control to give you ultimate control to spray paints or stains unthinned at any pressure
Flexible Suction Tube allows you to spray directly from a 1 or 5-gallon paint bucket
Supports up to 75 ft of paint hose to reach peaks or second stories without diminishing performance
Supports 10 TrueAirless Spray Tips giving you the flexibility to complete a number of projects with ease
General | |||
|---|---|---|---|
Collection/Series Name | Magnum X5 | Pump Type | Piston |
Series Name | Magnum X5 | Filter Type | 30-mesh |
Type | Stationary | Gun Trigger Type | 4-finger |
Power Source | Electric | Cup Fed | No |
Grade | Residential | Direct Syphon | Yes |
Use Location | Indoor/Outdoor | Spray Gun Material | Metal |
Airflow (CFM) | 0 | Material Flow Control | Yes |
Housing Material | Plastic | ||
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 14.375 | Minimum Fan Pattern Width (Inches) | 4 |
Direct Syphon Capacity | 1-5 gallon | Minimum Tip Size (Inches) | 0.009 |
Height (Inches) | 17.75 | Tip Size | 0.015-in |
Hose Length (Feet) | 25 | Tip Size Code | 515 |
Maximum Fan Pattern Width (Inches) | 10 | Weight (lbs.) | 13.3 |
Maximum Hose Length (Feet) | 75 | Width (Inches) | 12 |
Maximum Hose Length Capability (Feet) | 75 | Battery Amp Hours | 0 |
Maximum Tip Size (Inches) | 0.015 | Diameter of Hose Included | 1/4-in |
Features | |||
|---|---|---|---|
Actual Gallons per Minute | 0.27 | Multi-Directional Spray | Yes |
Adjustable Fan Pattern Control | Yes | Pressure Rating (PSI) | 3000 |
Adjustable Spray Pattern | Yes | Pump Replaceable | No |
Battery(s) Included | No | Spray Gun Filter | Yes |
Built-In Hose Swivel | No | Variable PSI | Yes |
Cordless | No | Voltage (Volts) | 110 |
Engine Horsepower | 0.5 | Wheeled | No |
Flow Rate (GPM) | 0.27 | Project Size | Large |
Compatibility | |||
|---|---|---|---|
For Use with Stains | Yes | For Use with Walls | Yes |
For Use with Latex Paints | Yes | For Use with Floors & Ceilings | Yes |
For Use with Oil Paints | Yes | For Use with Woodworking Projects | Yes |
For Use with Doors | Yes | For Use with Furniture & Cabinets | Yes |
For Use with Acrylic Paints | Yes | For Use with Decking | Yes |
For Use with Lacquers | No | For Use with Fencing | Yes |
For Use with Water-Based Paints | Yes | For Use with Oil-Based Stains | Yes |
For Use with Elastomerics | No | Use with Material Flash Point (Degrees) | 100 |
For Use with Urethanes and Varnishes | Yes | For Use with Primer | Yes |
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | Safety Listing | ETL safety listing | |
Warranty | |||
|---|---|---|---|
Warranty | 1-year limited | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 31211900 | ||
Ratings may include incentivized customer reviews.
What Customers Are Saying
The Graco Magnum X5 is a versatile and easy-to-use airless paint sprayer that provides a professional-quality finish. It can handle a variety of paint and stain types, and allows for faster painting compared to brushes or rollers. Users report being able to complete large projects efficiently. The sprayer is compact and lightweight, making it easy to move around. While some time is required for initial setup and thorough cleaning, the Graco Magnum X5 is widely praised as an excellent DIY tool that delivers high-quality results.
Customer review summary generated by AI, including incentivized reviews.Graco Magnum X5
Great little sprayer. Works as well as the bigger Graco sprayer I had for 25 years.
Verified Purchaser
I Painted like a Pro
Was getting a new impact resistant shingled roof on my barn and house along with new custom aluminum seamless gutters so I thought might as well put on a fresh coat of paint to go with it. I've always rolled and brushed I'm 63 so old school, but this time I seen the Graco airless spayers so I decided to investigate. Went home and investigated and watched a bunch of YouTube videos and was like heck yeah if its faster and easier and you get a better paint job I'm going for it. Went back to the pa...
From magnum.graco.com
Easy to Use and Great Price
I’ve had this on my list to buy for years. I finally did when I installed a new fence and needed to stain 150’ of 8’ fence. Instructions were very clear and well written. It easy to use and the stand makes it very portable. It was easy to setup and clean when done. I had no trouble spraying even lines and overspray is minimal. I look forward to my next project! This is well worth the money.
From magnum.graco.com
Amateur with Pro Results
Amateur with Pro Results - I painted two very large rooms (15 gallons of paint) - ceilings and walls. A lot of effort goes into the prep (masking.) Once done the spraying is easy and looks great. The instructions were clear and the unit was easy to manage and clean. I highly recommend this especially for coffered ceilings, and wainscoting panels.
From magnum.graco.com
Amazing paint machine
Painted my house super fast and super clean. Works great
Verified Purchaser
Great system.
This is the first airless sprayer that I’ve used in probably 35 years. Very much amazed at how far the industry have come with the improvements to airless systems. For me this Graco X5 is just what I needed for the jobs that I’ll have around the house for years to come.
From magnum.graco.com
Very pleased.
The X5 has great consistent pressure. It is much quieter than our old sprayer. Lightweight to carry since it doesn’t roll. It provided a beautiful finish on cabinets using fflp tip and holder.
From magnum.graco.com
Block walls in Arizona
We live in Arizona and our yard is bordered by cinder block walls that needed painting. We purchased the Graco X5 for this purpose. I’ve never used an airless paint sprayer before but this sprayer was easy to learn and use. We used 10 gallons of paint and cleanup was a breeze!
From magnum.graco.com
First Time Sprayer - Used for Kitchen Renovation
First time Paint Sprayer! My wife and I decided we would tackle a Kitchen renovation project which included painting our orange-looking wooden cabinets. We wanted a high-quality look , and I ran into too many YouTube videos showing Graco Sprayers. I chose to purchase the Magnum X5. I was immediately impressed at how easy the X5 was to use (after a very small learning curve). I literally did two practice sprays on cardboard before actually spraying my cabinet, and it just worked! The finish...
From magnum.graco.com
Hello MikeO, Thank you so much for the five‑star review! We’re thrilled to hear that your first experience with the Magnum X5 went so well—and that it...
Very pleased
Sprayer words very well. I painted about 100' of fence in no time with this where I believe it would have been several afternoons had I done it the old fashioned way Good startup directions. Good flushing directions. Easy to handle. Pleased with purchase
From magnum.graco.com
Hello Don East Texas, Thank you for the five‑star review and for sharing such a detailed experience! We’re thrilled to hear your Magnum X5 helped you ...
