Name: A.O. Smith Signature 100 50-Gallons Tall 4500-Watt Double Element Electric Water Heater Installation Bundle
Brand: A.O. Smith
SKU: GR_17696
Price: 633.46 USD

Items Included in this Collection

Everything you need for a safer, smoother installation! This bundle pairs a reliable A.O. Smith Signature 100 50-Gallons Tall 4500-Watt Double Element Electric Water Heater with essential components that help simplify installation, improve system safety, and support long-term performance so you can upgrade with confidence. A.O. Smith Signature 100 50-Gallons Tall 4500-Watt Double Element Electric Water Heater delivers reliable, energy-efficient hot water for your household. Eastman drain pan with fitting helps protect your home by capturing and redirecting leaks. Eastman thermal expansion tank absorbs excess pressure to help extend the life of your plumbing system. Eastman runoff tube for pressure relief valve supports safe operation by directing discharged water away. Eastman brass tank tee fitting provides a durable, corrosion-resistant connection for proper system setup. Eastman steel stand elevates the unit for added stability and code-compliant installations. Important installation notes: check local regulations, especially in seismic or high-movement areas, to ensure proper securing of the unit and expansion tank with water heater straps (recommended in this bundle).

Signature 100 50-Gallons Tall 6-year Warranty 4500-Watt Double Element Electric Water Heater

22-in ID Aluminum Water Heater Drain pan with PVC Fitting

A.O. Smith Signature 100 50-Gallons Tall 6-year Warranty 4500-Watt Double Element Electric Water Heater

Keep hot water flowing with A. O. Smith's Signature 100 Series 50-Gallon Tall Electric Water Heater. It's designed to provide efficient and reliable hot water for households with 3 to 5 people when sized appropriately. This model is designed to last and features dual copper heating elements, a protective anode rod and a ceramic fused tank shield designed to reduce corrosion and provide ultimate tank protection. A self-cleaning dip tube helps reduce sediment build-up and extend the overall life of the water heater. This added protection comes with a 6-year limited warranty to give you additional peace of mind. Want to save money on your energy bills? This 50-gallon hot water heater operates at a 0.92 Uniform Energy Factor (UEF) which can reduce your energy consumption compared to less efficient models. Call 1-877-GOLowes to get this water heater installed.

Delivers the ideal amount of hot water for households with 3 to 5 people when sized appropriately
Features two 4,500-watt copper heating elements that provide a first hour delivery of 62 gallons
Operates at a 0.92 Uniform Energy Factor for maximum energy-efficiency and cost savings
Tall, slim 59-in H x 20.5-in diameter profile enables easier installation in narrow spaces
Provides superior tank protection and extends water heater life with premium heating elements, anode rod and fused ceramic tank shield
Reduces heat loss with non-CFC polyurethane foam insulation and factory-installed heat trap nipples for maximum efficiency and energy savings
Features easy temperature control with adjustable thermostat you can set higher or lower for dishwashers and laundry machines
Provides peace of mind with a 6-year limited tank and parts guarantee and a 1-year limited labor warranty
Factory-installed temperature and pressure relief valve and tamper-proof drain valve ensures safe operation

General
Series Name	Signature 100	Grade	Residential
Type	Tank	Use Location	Indoor
Power Source	Electric

Dimensions
Depth (Inches)	20.5	Nominal Capacity (Gallons)	50
Diameter (Inches)	20.5	Rated Storage Capacity	46-Gallon
Family Size	5	Water Connection Size	3/4-in
Height (Inches)	59	Weight (lbs.)	125
Insulation Thickness (Inches)	2.25	Width (Inches)	20.5

Features
Annual Fuel Utilization Efficiency % (Percentage)	0	Scale Prevention	No
Foam Insulation	Yes	Super High Efficiency	Yes
GPH Recovery at 90 Degrees F (Gallons)	20.7	Temperature and Pressure Relief Valve	Yes
Grid Capable	No	Uniform Energy Factor	0.92
Hybrid Heat Pump Technology	No	Voltage (Volts)	240
Installation Location	Closet	Water Connection Location	Top
Point of Use	No	Water Heater Style	Tall

Compatibility
Bluetooth Compatibility	No	Works with iOS	No
Smart Compatible	No	Works with SmartThings	No
Wi-Fi Compatibility	No	Works with the Google Assistant	No
Works with Amazon Alexa	No	For Use with Mobile Homes	Yes
Works with Android	No	For Use with RVs	No
Works with Apple HomeKit	No

Warranty
Warranty	6-year limited

Certifications
CA Residents: Prop 65 Warning(s)	Prop 65 WARNING(S) -	Safety Listing	CSA safety listing
ENERGY STAR Certified	No	AHRI Certified	Yes

Miscellaneous
UNSPSC	40101800

Review

4.3 out of 5

5762 Reviews

87% Recommend this product

Ratings may include incentivized customer reviews.

+ 210

What Customers Are Saying

The water heater is generally easy to use and provides ample hot water, with many customers satisfied with its performance and quality construction. However, some customers reported issues with leaks, faulty heating elements, and thermostat problems, leading to the need to replace the unit within a short time. The long-term durability of the product is a concern, and customers should be prepared to address any defects promptly.

Customer review summary generated by AI, including incentivized reviews.

5762 Customer Reviews

Sort By

Buyer beware

Would Not Recommend

We had our first one for only 3 years and it took a crap, AO smith did warranty it so that was nice, Lowe’s was great handed us a gift card and we went and got the same one. Well here we are one year later and the heating element went out, save your money and go with a more name brand hot water heater these ones are junk

Not giving this outJuly 9, 2026

Was this Review Helpful ?

Response from Published by the A. O. Smith Team

We are sorry to hear of your experience. We want to ensure the issue is resolved.

Please send your phone number to talktous@aosmith.co...

Published by the A. O. Smith TeamJuly 10, 2026

Disappointed But Great Due to Customer Service

Would Recommend

I originally purchased an AO Smith Signature 100 50-Gallon Tall 6-Year Water Heater. Shortly after installation, I experienced an issue where the unit’s internal kill switch was tripping. I contacted AO Smith customer support, and they provided a PDF guide along with step-by-step instructions on what to inspect and what tests to perform using a multimeter. After troubleshooting, we determined that the top heating element was defective. I provided this information to AO Smith, and they promptly ...

MichaelJuly 9, 2026
Verified Purchaser

Was this Review Helpful ?

All good, be sure to ck spigot after removing box

Would Not Recommend

Plumber got installed, turned on water and discovered the plastic drain spigot was cracked and leaking. It took an extra hour and a half to remove the broken end from inside threads.

Dont have oneJuly 10, 2026
Verified Purchaser

Was this Review Helpful ?

Poor water heater installation

Would Not Recommend

Water heater installed and sputtered out water for 2 days until no more water in entire house since installation. Got phone tag run around and automated assistance. Still no water

paulJuly 17, 2026
From Signature 100 55-Gallon Tall 6-year Warranty 4500-Watt Double Element Electric Water Heater Verified Purchaser

Was this Review Helpful ?

I don't know what else to do!

Would Not Recommend

I bought this tank thinking that it would work, being that it is brand new. I have had problems with this tank every since it was installed. I am now on my third professional person coming out to check this water tank. Every person that has touched this tank has gotten hot water one day after and nothing more.

Ms CarelessJuly 2, 2026
Verified Purchaser

Was this Review Helpful ?

Response from Published by the A. O. Smith Team

We are sorry to hear of your experience. We want to ensure the issue is resolved.

Please send your phone number to talktous@aosmith.co...

Published by the A. O. Smith TeamJuly 6, 2026

The perfect electric water heater

Would Recommend

Great water heater! Each of the properties I have now has one of these and super easy to install. Had hot water a few hours after install

BrundJuly 6, 2026
Verified Purchaser

Was this Review Helpful ?

AO Smith poor service

Would Not Recommend

I purchased this product which was defective out of the box and was refused the ability to return/exchange it. I ended up paying out of pocket for the repairs made, totally unacceptable customer service from AO Smith. We purchased the heater in December, and the thermostats were bad. I offered to exchange it in store and AO Smith said I couldnt, that it had to be repaired. This forced me to pay a weekend rate for a licensed professional to come out and make the repairs (AO Smith's requirement fo...

ADFullerJune 26, 2026

Was this Review Helpful ?

Response from Published by the A. O. Smith Team

We're sorry to hear of your experience.

We want to ensure you receive the warranty coverage included with your purchase.

Pl...

Published by the A. O. Smith TeamJune 29, 2026

Good value

I need a new hot water heater so I purchased this one. The price was OK compared to others. Installation went well.

no noJuly 8, 2026
From Signature 100 40-Gallons Tall 6-year Warranty 4500-Watt Double Element Electric Water Heater Verified Purchaser

Was this Review Helpful ?

Just NO

Would Not Recommend

PRV leaked water all over when filling, never would seat. I can blow through it. I used old one to get by. The threaded insert for the PRV is installed at an angle in, thus the old overflow tube hits the unit. Had to go to Pex for a work around on that. Called Tech Support, after 20 minutes I left my number, Caleb returned the call I missed. Didn’t leave a callback or extension, I called back and went right back where I started. I’ll just go buy another PRV and be done. Case # 19840797 if y’al...

BriJune 26, 2026
From Signature 100 40-Gallons Tall 6-year Warranty 4500-Watt Double Element Electric Water Heater

Was this Review Helpful ?

Response from Published by the A. O. Smith Team

We're sorry to hear of your experience.

We want to ensure you receive the warranty coverage included with your purchase.

Pl...

Published by the A. O. Smith TeamJune 29, 2026

Unable to remove the sacrificial anode

Would Not Recommend

I was unable to remove the sacrificial anode, it was impossible to loosen. I even tried Impact wrenches. It would not come out. I callerd O.A. Smith and they said the water softwner was insured for 6 years. I said I wanted the ability to remove the anode on my unit, they said they would not loosen it nor replace the water heater. Thee anode usually lasts for 2-3 years at my location. DONT BUY THIS UNIT AS THE MANUFACTURER WILL NOT HONOR THEIR UNIT..

RussJune 22, 2026
