A.O. Smith Signature 100 50-Gallon Tall 40000-BTU Natural Gas Water Heater Installation Bundle
Collection Items
When should I expect to get my items?
See availability by item
Items Included in this Collection
Item #962540 |
Model #G6N-T5040NVR
Delivers the ideal amount of hot water for households with 5+ people when sized appropriately
Features an environmentally-friendly 40,000 BTU gas burner that delivers 81 gallons in the first hour
Electronic gas valve provides precise temperature control for optimum hot water delivery
Self-diagnostic electronic gas control incorporates an LED status indicator that monitors and reports on the system's operational status
Built-in safety system reduces the risk of accidental flammable vapor ignitions
Tall, slim 60.75-in H x 21-in diameter profile enables easier installation in narrow spaces
Tank Guard® provides advanced tank protection that extends the life of your gas water heater
High-altitude certified from 0 ft to 10,100 ft
Provides peace of mind with a 6-year limited tank and parts guarantee and a 1-year limited labor warranty
General | |||
|---|---|---|---|
Series Name | Signature 100 | Fuel Type | Natural gas |
Type | Tank | Ignition Type | Piezo |
Power Source | Gas | Venting Type | Atmospheric |
Grade | Residential | Vent Type | Type B double wall |
Use Location | Indoor | ||
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 21 | Rated Storage Capacity | 48-Gallon |
Diameter (Inches) | 21 | Vent Diameter(s) | 3-in |
Family Size | 5 | Water Connection Size | 3/4-in |
Height (Inches) | 60.75 | Weight (lbs.) | 148 |
Insulation Thickness (Inches) | 1.5 | Width (Inches) | 21 |
Nominal Capacity (Gallons) | 50 | ||
Features | |||
|---|---|---|---|
Annual Fuel Utilization Efficiency % (Percentage) | 0 | Pilot Reset Button | Yes |
BTU Rating | 40000 | Point of Use | No |
Emission Rating | Low NOx | Scale Prevention | No |
Foam Insulation | Yes | Super High Efficiency | No |
GPH Recovery at 90 Degrees F (Gallons) | 41 | Temperature and Pressure Relief Valve | Yes |
Grid Capable | No | Uniform Energy Factor | 0.62 |
High Altitude Model | Yes | Water Connection Location | Top |
Installation Location | Closet | Water Heater Style | Tall |
Pilot Light Window | Yes | ||
Compatibility | |||
|---|---|---|---|
Bluetooth Compatibility | No | Works with iOS | No |
Smart Compatible | No | Works with SmartThings | No |
Wi-Fi Compatibility | No | Works with the Google Assistant | No |
Works with Amazon Alexa | No | For Use with Mobile Homes | No |
Works with Android | No | For Use with RVs | No |
Works with Apple HomeKit | No | ||
Warranty | |||
|---|---|---|---|
Warranty | 6-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | AHRI Certified | Yes | |
ENERGY STAR Certified | No | AHRI Certification Number | 206911262 |
Safety Listing | CSA safety listing | ||
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 40101800 | ||
Ratings may include incentivized customer reviews.
What Customers Are Saying
The water heater is generally reliable and effective at heating water efficiently. Many users report the installation process is straightforward, with the unit fitting well in place of older models. However, some customers received defective units or experienced issues like leaks or the pilot light going out. Overall, the product performs well, but there are quality control and customer service concerns to consider.
Customer review summary generated by AI, including incentivized reviews.stopped working after 3 weeks
Bought A.O. Smith 30 gallon gas tank water heater from Lowes Los Angeles midtown on 12/17/25. Had it professionally installed. It stopped working three weeks later (10 blinks; requires air filter on what purports to be NEW water heater to be cleaned). No hot water! Submitted ticket on website 1/8/26. Customer Service phone contact number on A.O. Smith website (800) 527-1953 is a scam - nothing but adds to sell assorted unrelated products.
From Signature 100 30-Gallon Tall 6-year Warranty 32000-BTU Natural Gas Water Heater
don't bother trying to replace anode rod
Have had this water heater for about a year and a half. decided to replace the anode rod (supposed to be a serviceable and consumable part) with an electric one which would be better for my well water. I have been a mechanic, and a tradesman, for over 30 years. I know how to remove a bolt (which is basically what an anode rod is). Used a 1-1/16" impact socket and still rounded off the head. Used a 27MM extractor and that just reduced the size of the head. I am confident no one and nothing c...
From Signature 100 40-Gallons Tall 6-year Warranty 35500-BTU Natural Gas Water Heater
We are sorry to hear of your experience. We want to ensure the issue is resolved.
Please send your phone number to [email protected]...
failed after 2 months
When it worked, it did great, but after 2-ish months, the heater part dies- dont know how, but it did. If you are in the Houston area, do NOT use britton plumbing- they came out, 'fixed it' then 2 days late it failed again- now we had to wait several weeks for a replacement to be sent. if they had diagnosed it correctly the first time, then the house would have had hot water within a week vs three. DO NOT USE BRITTON PLUMBING.
From Signature 100 40-Gallons Tall 6-year Warranty 35500-BTU Natural Gas Water Heater
We are sorry to hear of your experience. We want to ensure the issue is resolved.
Please send your phone number to [email protected]...
AO Smith was Whirlpool, dimensionally the same.
Because this heater is identical to my old Whirlpool brand it basically dropped right in. Purchased it on-line, was at the store like ten minutes. Picked it up at 9 am and lit the pilot at 10:30. 40 gallon gas fired, Expensive at 600$
From Signature 100 40-Gallons Tall 6-year Warranty 35500-BTU Natural Gas Water Heater Verified Purchaser
Buyers Beware.Lowes restocks shelves w/ used goods
The water heater did not work. In working with the manufacturer it turned out the heater had been returned to Lowes' and was already registered to another customer! Lowes customer service was no help, no one even answered the phone for the first 20 minutes, Shania in Customer Service would not connect me with a manager who would help be order a new heater and have it shipped quickly to my local store, but kept insisting that she understood me but couldn't help. I was told to purchase anothe...
Verified Purchaser
We are sorry to hear of your experience.
We recommend reaching out to Lowe's Customer Care at 1-800-445-6937 or Text 84109.
Wrong gallon size delivered
I ordered and paid for a 50 gallon natural gas water tank. I was told that I could use their installation but I would have to call back the following day to get a quote for the price for the installation. The quote was $1500-$2100 simply to install the hot water heater. What was delivered to me was a 40 gallon natural gas water tank. I had the drivers take it back with them. And now I’m being told that I’ll have to wait a few more days before the correct one is sent out. I paid for a 50 gallon a...
Verified Purchaser
We are sorry to hear of your experience. We want to ensure the issue is resolved.
Please send your phone number to [email protected]...
Install
Lowe’s says on the box they have installers, once you have bought it you find out they don’t….its a bogus claim, at least in Alaska.
From Signature 100 30-Gallon Tall 6-year Warranty 32000-BTU Natural Gas Water Heater Verified Purchaser
I'm very impressed with the water heater
Old one expired after 16 years (not bad). This one fit in the space the old one occupied very well. The professional plumber said AO Smth makes good products and rececommended it. If this one lasts as long as the old one, I will be satisfied. So far, so good.
From aosmith.com
.
Works great, pickup was easy
Verified Purchaser
Easy Install and Use
I bought this to replace my old 40 gallon. The difference has been night and day. We have more than enough capacity for my family of 5 to bathe while dishes or laundry is running.
