A.O. Smith Signature 100 40-Gallon Tall 36000-BTU Liquid Propane Water Heater Installation Bundle
Collection Items
SUCCESSWhen should I expect to get my items?
See availability by item


Items Included in this Collection



Item #1325041 |
Model #G6-T4036PVR
Delivers the ideal amount of hot water for households with 3 to 4 people when sized appropriately
Features an environmentally-friendly 36,000 BTU ultra-low NOx burner that delivers 80 gallons in the first hour
Electronic gas valve provides precise temperature control for optimum hot water delivery
Self-diagnostic electronic gas control incorporates an LED status indicator that monitors and reports on the system's operational status
Built-in safety system reduces the risk of accidental flammable vapor ignitions
Tall, slim 61.75-in H x 20-in diameter profile enables easier installation in narrow spaces
Tank Guard® provides advanced tank protection that extends the life of your gas water heater
High-altitude certified from 0 ft to 10,100 ft
Provides peace of mind with a 6-year limited tank and parts guarantee and a 1-year limited labor warranty
General | |||
|---|---|---|---|
Series Name | Signature 100 | Fuel Type | Liquid propane |
Type | Tank | Ignition Type | Piezo |
Power Source | Gas | Venting Type | Atmospheric |
Grade | Residential | Vent Type | Type B double wall |
Use Location | Indoor | ||
Dimensions | |||
|---|---|---|---|
Depth (Inches) | 19.75 | Rated Storage Capacity | 38-Gallon |
Diameter (Inches) | 20 | Vent Diameter(s) | 3-in; 4-in |
Family Size | 4 | Water Connection Size | 3/4-in |
Height (Inches) | 61.75 | Weight (lbs.) | 135.75 |
Insulation Thickness (Inches) | 2 | Width (Inches) | 19.75 |
Nominal Capacity (Gallons) | 40 | ||
Features | |||
|---|---|---|---|
Annual Fuel Utilization Efficiency % (Percentage) | 0 | Pilot Reset Button | Yes |
BTU Rating | 36000 | Point of Use | No |
Emission Rating | Ultra Low NOx | Scale Prevention | No |
Foam Insulation | Yes | Super High Efficiency | No |
GPH Recovery at 90 Degrees F (Gallons) | 42 | Temperature and Pressure Relief Valve | Yes |
Grid Capable | No | Uniform Energy Factor | .64 |
High Altitude Model | Yes | Water Connection Location | Top |
Leak Detection | No | Water Heater Style | Tall |
Pilot Light Window | Yes | ||
Compatibility | |||
|---|---|---|---|
Bluetooth Compatibility | No | Works with iOS | No |
Smart Compatible | No | Works with SmartThings | No |
Wi-Fi Compatibility | No | Works with the Google Assistant | No |
Works with Amazon Alexa | No | For Use with Mobile Homes | No |
Works with Android | No | For Use with RVs | No |
Works with Apple HomeKit | No | ||
Warranty | |||
|---|---|---|---|
Warranty | 6-year limited | ||
Certifications | |||
|---|---|---|---|
CA Residents: Prop 65 Warning(s) | Safety Listing | CSA safety listing | |
ENERGY STAR Certified | No | AHRI Certified | Yes |
Miscellaneous | |||
|---|---|---|---|
UNSPSC | 40101800 | ||
Ratings may include incentivized customer reviews.
What Customers Are Saying
Customers overwhelmingly praise this water heater for reliable hot water delivery, fast recovery in as little as 45 minutes, and straightforward installation. Many highlight consistent performance through back-to-back showers, quiet operation, and durable construction, with several referencing previous units lasting 22 to 25 years. The compact design and energy efficiency receive strong approval. A small group reports pressure relief valve leaks and occasional burner noise, while a few mention difficulty accessing qualified service technicians. Overall, most customers consider it a dependable, well-built investment.
Customer review summary generated by AI, including incentivized reviews.Propane water heater
The propane water heater works well. Easy to install. Only problem is it costs $200 more than natural gas. What a rip off from the propane association.
Verified Purchaser
Easy Peazy Pick-up
I asked for a little Associate assistance with the transaction and "Boom". An exceptionally talented Associate jumped right in and walked me through the process of picking up my Gas Hot Water Heater. They even loaded it for me in my truck. I was then on my way. Could not have been more pleased with the process. Oh!, P.S. I got a Pro to install for me. Took about an hour. Minimum cost.
From Signature 100 50-Gallon Tall 6-year Warranty 37000-BTU Liquid Propane Water Heater Verified Purchaser
New tank with a broken pressure relief valve
After installing the hot water tank, water kept coming out of the pressure relief valve. We had to go to a hardware store to purchase a new pressure relief valve and replace it. Major inconvenience and had to spend more money. Works great now.
From Signature 100 50-Gallon Tall 6-year Warranty 37000-BTU Liquid Propane Water Heater Verified Purchaser
Ease of installation.
Verified Purchaser
Buyer beware! A.O. Smith warranty is a NIGHTMARE!
I wouldn't even give it 1 star if I didn't have to in order to rate it. My husband and I just replaced our 24yo A.O. Smith propane water heater on Tuesday. We figured our previous heater lasted so long, why not go with it again. We were without hot water for 5 days until we could find someone to install it for us. After installation, the pressure valve kept dripping out of the drain tube. We had hot water and were told to wait for any residual air to leave the hot water lines and it should st...
From Signature 100 50-Gallon Tall 6-year Warranty 37000-BTU Liquid Propane Water Heater
Broken Upon receiving
Hot water heater was damaged on the inside. Welds are crap. Do not buy it. This is poor quality and definitely would not recommend buying this to anyone.
From Signature 100 50-Gallon Tall 6-year Warranty 37000-BTU Liquid Propane Water Heater Verified Purchaser
"We are sorry to hear of your experience. We want to ensure the issue is resolved.
Please send your phone number to talktous@aosmi...
Concerned
We purchased the AO Smith 50 gal propane water heater today (01/24/26) and after the plumber had installed the water heater he tested for gas leaks and his sensor indicated a leak in the control box. So he had to shut it down until we can determine the source of the leak. In the meantime we are without hot water.
From Signature 100 50-Gallon Tall 6-year Warranty 37000-BTU Liquid Propane Water Heater
We are sorry to hear of your experience. We want to ensure the issue is resolved.
Please send your phone number to talktous@aosmith.co...
Good, But Hard to Find Parts
Our water heater was installed seven years ago and it quit working. The warranty was for six years. The status light would not flash and the pilot light would not stay lit. A service company said it was the gas control valve, but they wanted too much money to replace it, so I did it myself. I could not find any part numbers for any parts on the AO Smith website, but I did get the valve part number off of the valve itself and found one online. It worked one time, then quit and would not work...
Verified Purchaser
Lowe's Pick up
Lowe's pickup was a bit confusing as there new area has both a locker style pick up and a bulk area pickup. The key pads are on either side of the door way so if one does not work it does not tell you to check the other. The water heater was simple enough to install and works well.
From Signature 100 50-Gallon Tall 6-year Warranty 37000-BTU Liquid Propane Water Heater Verified Purchaser
New water heater
Excellent price and the sales person was super nice and helpful. It fit in our car and the installation through Lowe’s was excellent. And an excellent price.
Verified Purchaser



We're sorry to hear you're having trouble with your water heater. We want to ensure you receive the warranty coverage included with your purc...
